Summary of Contents for Grundig SPACE FIDELITY PA 6

  • Page 1 SPACE FIDELITY PA 6 ENGLISH...

  • Page 2: Table Of Contents

    CONTENTS ________________________________________________________________________ PA 6 HiFi System Special features of your HiFi system Packing contents Set-up and safety Overview The HiFi system controls The HiFi display The remote control Preparation and connection Inserting batteries in the remote control Connecting the loudspeaker module Installing the speaker caps Attaching the wing panels to the HiFi Connecting the antenna...
  • Page 3 Playing back tracks in a selected order – creating a track memory Entering or deleting CD names Cassette mode General information about cassette mode Playback Recording Recording a CD on to cassette (CD COPY) Information Technical data Rectifying minor problems General instructions for laser devices GRUNDIG customer service locations...

  • Page 4: Pa 6 Hifi System

    PA 6 HIFI SYSTEM _____________________________________________________ Special features of your HiFi system Perfect sound is not a question of size, but of quality. This system gives you clear and vivid sound for any kind of musical style, packaged in a timeless design. The PA 6 is an elegant combination with RDS tuner, CD and cassette function.

  • Page 5: Set-Up And Safety

    SET-UP AND SAFETY ______________________________________________ To ensure that this high-quality, easy-to-use HiFi system will provide lasting satisfaction and enjoyment, please observe the following instructions when 1,5 - 3 m 1,5 - 3 m setting it up: OPEN/CLOSE DISC OPEN/CLOSE TAPE 30 cm This HiFi system is designed for the playback of audio signals.
  • Page 6 SET-UP AND SAFETY _________________________________________________________________ Thunderstorms present a danger to all electrical devices. Even if the HiFi is switched off, it can be damaged by a lightning strike to the mains. Always DISC OPEN/CLOSE TAPE OPEN/CLOSE disconnect the mains and antenna plugs during a storm. If the stereo system no longer scans CDs perfectly, use a commercially available cleaning CD to clean the laser optics.

  • Page 7: Overview

    OVERVIEW ________________________________________________________________________ The HiFi system controls Operating controls on the top side of the system POWER Switches the HiFi system on and off. The HiFi is completely disconnected from the power supply. The button contains a stand-by and mode indicator. POWER Switches »...
  • Page 8 OVERVIEW __________________________________________________________________________________ Operating controls on the front DISC Opens and closes the CD compartments. OPEN/CLOSE TAPE Opens and closes the tape compartment. OPEN/CLOSE DISC OPEN/CLOSE DISC SELECT Selects the CD in compartment 1, 2 TAPE OPEN/CLOSE 1 2 3 or 3 for playback. Headphone jack for connecting a stereo headphone set with a jack plug (ø...

  • Page 9: The Hifi Display

    OVERVIEW __________________________________________________________________________________ The HiFi display Stereo indicator. Fast forward/rewind of cassette, depending on the running direction. Playback of a CD or cassette. Cassette deck mode selected. Cassette deck functions: – Playback/recording stops at the end of each side of the cassette. –...

  • Page 10: The Remote Control

    OVERVIEW __________________________________________________________________________________ The remote control Buttons for general functions Switches the HiFi to Stand-by. The green indicator in the button and the green light on the front of the system are lit. RECORD CD-COPY Switches the HiFi on from Stand-by mode and selects ”CD” PAUSE operating mode.
  • Page 11 OVERVIEW __________________________________________________________________________________ Tuner mode buttons MEMORY Press this button and briefly hold it down to activate the automatic station search (AUTO STORE). Stores radio stations for the AUTO TUNING and MANUAL TUNING functions. RECORD CD-COPY PAUSE Press briefly to change the frequency in incremental MEMORY steps (MANUAL TUNING).
  • Page 12 OVERVIEW __________________________________________________________________________________ CD mode buttons DISC Selects the CD compartments 1, 2 and 3. Ends CD playback. RECORD CD-COPY PAUSE Starts CD playback. PAUSE Pauses CD playback. MEMORY TUNER Search for particular passages during CD playback. CANCEL BASS SOUND Select desired track. TAPE CTRL MODE...
  • Page 13 OVERVIEW __________________________________________________________________________________ Tape mode buttons Ends playback of the cassette. PAUSE Starts and pauses playback of the cassette. RECORD CD-COPY Starts playback of the cassette and reverses the PAUSE running direction. MEMORY TUNER Fast forward or rewind. CANCEL BASS Press during playback to search forwards or SOUND TAPE CTRL...

  • Page 14: Preparation And Connection

    PREPARATION AND CONNECTION _______ Preparation Inserting batteries in the remote control Open the battery compartment by pushing back and removing the lid. When inserting batteries (micro type LR 03, 2 x 1.5 V) make sure the polarity is correct. Note: If the HiFi no longer reacts properly to remote control commands, the batteries may be flat.

  • Page 15: Connecting The Loudspeaker Module

    PREPARATION AND CONNECTION _______________________________________ Connecting the loudspeaker module Connect the plug of the loudspeaker module with the plug of the HiFi. Note: The connecting cables need to be placed behind the loudspeaker module. Please note that the top side of the loudspeaker module is marked appropriately.

  • Page 16: Installing The Speaker Caps

    PREPARATION AND CONNECTION _______________________________________ Installing the speaker caps Attach the speaker caps supplied to both sides of the loudspeaker module. Attaching the wing panels to the the HiFi The wing panels are only standard parts for the PA 6/II and PA 6/III. They are also available as additional accessories for the PA 6/I at your authorised dealer (order No.

  • Page 17: Connecting The Antenna

    PREPARATION AND CONNECTION _______________________________________ Connecting the antenna Plug the rooftop antenna connector into the » FM 75 « socket on the HiFi. Note: If you do not have a rooftop antenna, use the auxiliary wire aerial supplied. This antenna provides a reasonably good reception for local stations. Do not shorten the auxiliary antenna.

  • Page 18: Connecting The Mains Cable

    PREPARATION AND CONNECTION _______________________________________ Connecting the mains cable Plug the mains cable into the socket. Selecting the HiFi antenna setting This setting enables you to adapt the HiFi to the antenna used. If you are using a cable connection from a public or private provider, select the »CABLE«...

  • Page 19: Settings

    SETTINGS ____________________________________________________________________________ Tuning to radio stations There are 59 preset positions for storing radio stations. There are two ways to set the preset stations: The first method is to initiate an automatic search. The HiFi automatically stores all stations which can be received at your location. The second method allows you to search for a station directly and then store it manually with the preset number of your choice.

  • Page 20: Automatic Search Programme (Asp)

    SETTINGS ____________________________________________________________________________________ Automatic search programme (ASP) Initiating the automatic search programme Note: The automatic search deletes all previously stored channels. Switch on the HiFi by pressing the »POWER « button on the HiFi. Select the input source »TUNER« with the »TUNER «...

  • Page 21: Tuning To A Radio Station Using The Manual Station Search

    SETTINGS ____________________________________________________________________________________ Tuning to a radio station using the manual station search Switch on the HiFi by pressing the »POWER « button on the HiFi. Select the input source »TUNER« with the »TUNER « button. Begin the station search by pressing and holding down »8« or »9«. FM 106.45 –...

  • Page 22: Sorting And Deleting Preset Stations

    SETTINGS ____________________________________________________________________________________ Sorting and deleting preset stations Deleting preset stations You can delete individual stations or, for example after moving house, all of them at once. Switch on the HiFi by pressing the »POWER « button on the HiFi. Select the input source »TUNER« with the »TUNER «...

  • Page 23: Manually Entering And Deleting Names For Radio Stations

    SETTINGS ____________________________________________________________________________________ Select the number of the station to be deleted (in this case 1) with » « or » « and press »CANCEL « to delete it. Select the station that is to be moved (Bayern 3) with » «...

  • Page 24: Adjusting The Brightness Of The Display

    SETTINGS ____________________________________________________________________________________ Move on to the next space with »+ « and continue your entry. 15 P_ _ You can move the cursor back one space by pressing » – «. Press »MEMORY« to store the setting. 15 POP 1 Note: To enter additional names repeat steps to 7.

  • Page 25: General Functions

    HiFi are lit. WELCOME TO GRUN – When you first switch on the HiFi system it is muted for approximately WELCOME TO GRUNDIG SPACE three seconds. The display reads: » FIDELITY «. – The input source which was selected before the HiFi was switched off is auto- matically activated.

  • Page 26: Adjusting The Volume

    GENERAL FUNCTIONS _____________________________________________________________ Adjusting the volume Adjust the volume with either the remote control »+« or » – « on the HiFi. VOLUME 16 – The display reads: » VOLUME « from » 0 « to » 6 3 «. Adjusting the bass and treble Activate the setting with »BASS...

  • Page 27: Muting The Hifi System

    GENERAL FUNCTIONS _____________________________________________________________ Selecting sound types Select the desired sound type by using the »SOUND CTRL« button. FLAT – The display reads: » FLAT «, » JAZZ «, » DISCO «, » VOCAL «, » USER I «, » USER 2 « or »...

  • Page 28: Tuner Mode

    TUNER MODE ________________________________________________________________ Basic Tuner mode functions Selecting the Tuner as the source Select the input source by pressing »TUNER « on the remote control, TUNER press »SOURCE« on the HiFi repeatedly until »TUNER« is shown in the display. – The display reads: » TUNER «, then the name of the station and the I BAYERN 3 frequency of the most recently selected preset station.

  • Page 29: Rds Reception

    TUNER MODE _____________________________________________________________________________ RDS reception Changing the HiFi system display To switch the display press » « repeatedly. – The display will show, in the following order: the RDS time, Radiotext, the frequency and the name of the station. RDS programme service I BAYERN 3 RDS stations in the VHF (FM) frequency band also transmit their station names.
  • Page 30 TUNER MODE _____________________________________________________________________________ PTY programme type code RDS provides the option of selecting FM stations according to programme type. A total of 29 programme types are defined. 12 Nachrich Call up the programme type with »PTY«. Select the desired programme type with » «...
  • Page 31 TUNER MODE _____________________________________________________________________________ Selecting the language for programme information You can choose between German and English as the language for the display of the programme types. Switch off the HiFi by pressing the »POWER « button. Press and hold »PTY« and press the »POWER «...

  • Page 32: Cd Mode

    CD MODE ___________________________________________________________________________ Basic CD mode functions General information about CDs Always hold CDs by the edge in order to avoid damaging them. Replace CDs in their jewel cases after use. Do not attach adhesive labels to CDs. Keep the surfaces of CDs clean. To clean CDs use a lint-free cloth and wipe them in a straight line from the centre of the disc outwards.
  • Page 33 CD MODE ____________________________________________________________________________________ Place the CD in the compartment with the label facing upwards. Press »DISC OPEN/CLOSE« on the HiFi to close the CD compartment. – The CD compartment closes, the display shows: »CLOSing«. closing – The HiFi reads the contents of the CD and the message: »READING D I « appears in the display.

  • Page 34: Repeating The Current Track

    CD MODE ____________________________________________________________________________________ Selecting a particular track Keep pressing » « or » « until you see the number or name of the required track in the display. 6 00 : 00 D I – Playback of the selected track starts automatically. Repeating the current track Press »...

  • Page 35: Special Cd Mode Features

    CD MODE ____________________________________________________________________________________ Special CD mode features Playing back tracks in random order (Shuffle function) This function allows the tracks to be played back in random order. shuffle OFF Select the function by pressing »MODE« once. The message »SHUFFLE OFF« is displayed. shuffle ON Select the »SHUFFLE ON«...

  • Page 36: Playing Back Tracks In A Selected Order - Creating A Track Memory

    CD MODE ____________________________________________________________________________________ Playing back tracks in a selected order – creating a track memory This function allows you to store and play back up to 50 tracks of the three CDs in any chosen order. Note: The track memory is deleted if the CD compartment is opened. Selecting and storing tracks Switch on the system by pressing the »POWER...
  • Page 37 CD MODE ____________________________________________________________________________________ Checking the track selection To check the stored tracks, press »MEMORY« for 2 seconds. Select the track with » « or » «. Playing back the track memory To start the playback of the track memory press » PAUSE«.

  • Page 38: Entering Or Deleting Cd Names

    CD MODE ____________________________________________________________________________________ Entering or deleting CD names Entering names for CDs You can enter up to 100 CD names. The names can be up to 11 characters long. The name will then appear each time the CD is placed in the CD compartment or selected.

  • Page 39: Erase All

    CD MODE ____________________________________________________________________________________ Deleting the names of all CDs To delete the names of all CDs, keep » « pressed for a moment. Abba live – The display shows the name of the CD. Press »CANCEL « until »ERASE ALL ?« appears in the menu. erase all ? By letting go of the »CANCEL...

  • Page 40: Cassette Mode

    CASSETTE MODE _________________________________________________________ General information about cassette mode Protect your cassettes from humidity, dust, heat and cold. Do not store your cassettes near devices with strong magnetic fields such as television sets or stereo speakers. After using a cassette, put it back in its protective case. Keep tape-guiding parts such as pich roller, capstan, magnetic heads and erase heads free of dirt and dust to maintain a good recording and playback quality.
  • Page 41 CASSETTE MODE ________________________________________________________________________ Insert the cassette into the compartment with the open side facing the back. Note: If you insert a cassette into the cassette compartment with side A facing upwards, » PAUSE« will begin the playback/recording on side A, »...

  • Page 42: Playback

    CASSETTE MODE ________________________________________________________________________ Playback Selecting the playback mode Select this function by pressing »MODE« twice. The display will show the message »CONT PLAY«, »AUTOREVERSE« or »REVERSE OFF«. Select function with » « or » «. cont. play – »CONT. PLAY« – playback of both sides of the cassette is repeated indefinitely.

  • Page 43: Track Search

    CASSETTE MODE ________________________________________________________________________ Track search This function allows you to search for individual tracks on the cassette. Up to 15 tracks can be skipped in either direction. Press »9« or »8« repeatedly during playback. – The display shows » « or » «.

  • Page 44: Recording

    CASSETTE MODE ________________________________________________________________________ Storing a position on the cassette To mark a position on the cassette, press »MEMORY« during playback at the desired point of the tape. – The display shows: »X«. Press » « after playback is stopped. The tape is wound to the marked spot and stops there.
  • Page 45 CASSETTE MODE ________________________________________________________________________ Recording Activate Dolby Noise Reduction if required. The setting procedure is described in the ”Noise reduction system (Dolby NR)” section on Page 41. 1050 Insert a cassette with the protection tabs intact into the cassette compartment, select the running direction of the cassette with » «...

  • Page 46: Recording A Cd On To Cassette (Cd Copy)

    CASSETTE MODE ________________________________________________________________________ Recording a CD on to cassette (CD COPY) You can start the recording process from CD on to cassette by pressing only one button. Individual tracks of a CD or music programme can be distributed on both sides of the cassette in this manner, so that long, empty passages at the end of a cassette are avoided.

  • Page 47: Information

    INFORMATION _____________________________________________________________ Technical data This device is noise-suppressed according to the applicable EC directives. This product fulfills the European directives 89/336/EEC, 73/23/EEC and 93/68/EEC. This device conforms to the safety regulation DIN EN 60065 (VDE 0860) and therefore the international safety regulation IEC 60065.
  • Page 48 INFORMATION __________________________________________________________________________ Rectifying minor problems Not every kind of sound interference is caused by a defect in your HiFi system. Impairment can also be caused by leads having been accidentally pulled out, damaged CDs and worn out batteries in the remote control. If the following measures do not bring about satisfactory results, consult an authorised dealer.

  • Page 49: Rectifying Minor Problems

    RECTIFYING MINOR PROBLEMS ____________________________________________ CD MODE PROBLEM Possible cause/remedy The CD compartment does not close. CD not inserted correctly. Playback is not functioning. The CD is dirty, scratched or upside down. A sudden temperature change has caused condensation on the laser lens system.
  • Page 50 INFORMATION __________________________________________________________________________ GRUNDIG customer service locations GRUNDIG GRUNDIG GRUNDIG GRUNDIG GRUNDIG Kundendienst Nord Kundendienst West Kundendienst Mitte Kundendienst Süd Kundendienst Ost Kolumbusstraße 14 Horbeller Straße 19 Dudenstraße 45-53 Beuthener Straße 65 Wittestraße 30e D-22113 Hamburg D-50858 Köln D-68167 Mannheim D-90471 Nürnberg...
