C-SCOPE CS5MX Manual page 3

Controls
3
5
1
2
4
6
7
CS2MX
8
CS2MX
10
CS5MX
8
CS5MX
14
10
1 Battery Compartment
2 Upper Stem & Handle Grips
3 Din Plug & Socket
4 Stem Connecting Nut
5 Cable
6 Lower Stem
7 Search Head Fastener
8 Power On / Off & Sensitivity
9 All Metal Mode / Discrimination 1
10 Pinpoint
11 Disc 2 Select
12 Discrimination 2
13 Signal Meter (CS5MX only)
14 Boost Hi / Normal (CS5MX only)
15 Battery Check (CS5MX only)
9
11 12
13 9
15 11 12
