Spilt screen with route guidance

10
7
8
9
6
5 4
1 Speed limit on the road currently be-
ing driven on (display not available for
all roads)
2 Route
3 Vehicle position
4 Road to which the next driving ma-
noeuvre leads/ current road
5 Distance to next driving manoeuvre
6 Traffic lane recommendation (only
appears on some multi-lane roads; red
arrows = recommended lanes)
Note:
Following the traffic lane recommenda-
tions allows you to perform the next driv-
ing manoeuvre without changing lanes.
7 Vehicle speed and altitude above sea
level
1
Note:
2
If two driving manoeuvres are to be per-
formed in quick succession, a small arrow
3
which indicates the second driving ma-
noeuvre appears instead of this informa-
tion.
8 Next driving manoeuvre
9 Progress bar to illustrate the distance
to the next driving manoeuvre
10 Estimated time of arrival, remaining
journey time and remaining distance
to destination

Route guidance with arrow display

8
6
7
1 Speed limit on the road currently be-
ing driven on (display not available for
all roads)
2 Next driving manoeuvre
3 Traffic lane recommendation (only
Note:
Following the traffic lane recommenda-
tions allows you to perform the next driv-
ing manoeuvre without changing lanes.
4 Road to which the next driving ma-
5 Distance to next driving manoeuvre
6 Progress bar to illustrate the distance
7 Vehicle speed and altitude above sea
Estimated time of arrival, remaining jour-
ney time and remaining distance to desti-
nation.
1
2
5
3
4
NAVIGATIONAL MODE
appears on some multi-lane roads; red
arrows = recommended lanes)
noeuvre leads/ current road
to the next driving manoeuvre
level
>>>
