>>> NAVIGATIONAL MODE

Entire map with route guidance

> D
> GB
7
> F
9
> I
> E
8
1 Road to which the next driving ma-
> NL
noeuvre leads
2 Vehicle speed and altitude above
sea level
3 Route
4 Vehicle location
5 Speed limit on the road currently be-
ing driven on (display not available for
all roads)
6 Traffic lane recommendation (only
appears on some multi-lane roads; red
arrows = recommended lanes)
Note:
Following the traffic lane recommenda-
tions allows you to perform the next driv-
ing manoeuvre without changing lanes.
52
7 Estimated time of arrival, remaining
5
8 Distance to next driving manoeuvre
3
4
9 Next driving manoeuvre
2
6
If the navigation function has been acti-
1
vated, the position icon will indicate your
current location on the map.
Depending on which setting was made
in option mode, the position icon may re-
main stationary while the map moves, or
vice versa.
journey time and remaining distance
to destination
and currently travelled road.
Information appears in the bottom left
corner of the preview area.
The distance remaining is indicated by
means of the number of kilometres (or
miles) below an arrow. If there are two im-
pending driving manoeuvres in quick suc-
cession, a small arrow appears over the
first manoeuvre to indicate that another
one is coming up.
