- Page 1 The Da-Lite Difference. Instruction Book for DA-LITE SCREEN COMPANY, INC. 3100 North Detroit Street Fast-Fold® truss Frame Post Office Box 137 Warsaw, Indiana 46581-0137 Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 www.da-lite.com e-mail: info@da-lite.com...
- Page 2 INSTRUCTIONS Unfold the 4 sections of truss frame, lock all latches and lay face up on the floor. 2. A ttach top and bottom sections to side sections using speedy cranks. Observe color tapes so they match. 3. Unfold truss feet located in top and bottom truss sections to raise frame off the floor. N OTE 1: Frames have rivnuts at the hinge points on the top and bottom sections. Insert a speedy crank through the unthreaded rivnut and tighten into the threaded rivnut. This will lock hinge joint securely. N OTE 2: On screens 25'and over, another section of 6"...
- Page 3 FaST-FOld TRUSS FRaME CONSTRUCTION ® UNDER 25' WIDE SCREEN SURFACE LEFT SIDE OF TRUSS FRAME SIDE TRUSS IS REMOVED FOR BETTER DETAIL OF CORNER ASSY. VIEWING OF TRUSS LEG. FASTEN TRUSSES WITH SPEEDY CRANKS MAKE SURE SPEEDY CRANK IS INSERTED THROUGH ALL THREADED HINGE JOINTS BOTTOM TRUSS TRUSS LEG ANTI-SWAY BRACE (MOUNTED OUTSIDE WHEN A-BRACE USED WITH DRAPES) ANTI-SWAY BRACE (MOUNTED INSIDE WHEN USED WITHOUT DRAPES) BACK FOOT FRONT FOOT 25' AND WIDER SHORT SPEEDY CRANK DIAGONAL BRACE SHORT SPEEDY CRANK SCREEN SURFACE ASSEMBLED END VIEW OF FRAME AND “L ” SECTION TRUSS “L ” SECTION SIDE TRUSS...
- Page 4 Printed in U.S.A. 47404 Rev. 10/09...
