3. Press down the CPU socket lever and finish
CPU installation.
Note: This picture is for example only; it may not exactly be the same with your motherboard.
4
B
U
2
4
B
U
2
Note: If you do not match the CPU
socket Pin 1 and CPU cut edge well,
you may damage the CPU.
CPU cut edge
Note:
Micro-FC-PGA2 package CPU, the
latest CPU package developed by
Intel. Other forms of CPU package
are impossible to be fitted in.
Note: P4 CPU tends to produce higher
temperature; for better heat dissipation,
we
recommend
motherboard with a bigger housing.
Besides, by doing so you can prevent
components from colliding.
