If the housing has been designed with an audio port on the front panel, you'll be able to connect onboard audio to front panel
through this connector. By the way, please remove the jumper cap from the Front Audio Connector before you connect the cable.
Do not remove this yellow jumper cap if your housing doesn't have an audio port on the front panel.
Pin 1
1
2
MICIN1
GND
MICIN2
+5V
PHONE_R
SP-OUT R
NC
SP-OUT L
PHONE_L
NC
9
10
4
B
U
2
4
B
U
2
n
e
c
t
o
r
n
e
c
t
o
r
Note: Please remove the jumper cap from the front audio connector before
you connect the cable. Do not remove this yellow jumper cap if your housing
doesn't have an audio port on the front panel.
