I Charging Connections - Icom IC-4088SR Instruction Manual

3
BATTERY CHARGING

I Charging connections

D D Regular charging with the BC-149D, CP-18E
➥ Connect the optional BC-149D
LIGHTER CABLE
• Charging period: approx. 15 hours
IMPORTANT!:
Use the BC-149D or CP-18E ONLY. Other type of AC adapter,
cigarette lighter cable or DC power cable with an external power
supply may damage the transceiver.
The optional BP-202 can only be charged— other AA (R6) size
rechargeable Ni-Cd cannot be charged.
BE SURE to disconnect the CP-18E from the cigarette lighter
socket when charging is finished, because, a slight current still
follows in the CP-18E and the vehicle's battery will become ex-
hausted.
6
to [DC 6V].
to [DC 6V]
jack
or CP-18E
AC ADAPTER
Optional CP-18E
Cigarette lighter cable
with DC-DC converter
Optional BC-149D
CIGARETTE
to cigarette
lighter socket
to AC outlet
