Front routing:
a. Unwind the power cord and route it under the upright.
b. Slide the grommet into the front exit hole with the curved end first. See Figure 10.
c. Wire tie the cord down. See Figure 10.
Grommet
Wire Tie
Figure 10
Back routing:
a. Using a Phillips head screwdriver, remove the left end cap.
b. Remove the grommet from the back exit hole and slide it into the front exit hole.
c. Slide the grommet on the power cord into the back exit hole with the curved end first.
d. Using a Phillips head screwdriver secure the left end cap. See Figure 11.
Grommet
Slot at
Front of
Treadmill
Figure 11
B.
Wind the excess power cord onto the arms. See Figure 11.
C.
Place the left side panel into position slightly under the end cap and use your hand to push all
along the bottom edge of the side panel to snap it in place.
Assembly
and
Setup
Page 2-8
Cybex Pro Treadmill Owner's Manual
3
Wire Tie
Arms
Arms
End
Cap
Screw
