Figure 7
B.
Using the Allen wrench provided, tighten the two pivot screws on the handrail. See Figure 8.
Figure 8
9. Remove the left side panel.
A.
Pull the left side panel away from the base. See Figure 9.
Left Side Panel
Figure 9
10. Arrange power cord.
A.
Decide whether you will plug the power cord into an outlet near the front of the treadmill or the
back of the treadmill. Follow the corresponding routing procedure below. NOTE: Do not plug in
the power cord at this time.
Cybex Pro
Treadmill Owner's Manual
3
3
Pivot
Screws
Assembly
and
Setup
Page 2-7
