  • Page 5 Deutsch English Systembaugruppe D1184 System Board D1184 Technisches Handbuch Technical Manual Ausgabe September 2000 September 2000 edition...
  • Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright ã Fujitsu Siemens Computers GmbH 2000 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
  • Page 7: Table Of Contents

    Write protection for floppy disks - switch 3 ................10 Add-on modules ..........................11 Installing / removing processor ....................12 Upgrading main memory......................13 Upgrading GPA memory......................14 Installing network board with WOL................... 14 Replacing the lithium battery....................15 Glossary ............................16 A26361-D1184-Z120-3-7419...
  • Page 9: Introduction

    Please note the information provided in the chapter "Safety" in the Operating Manual of the device. Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore essential to observe the instructions in the chapter „Add-on modules“ - „Replacing the lithium battery“. English - 1 A26361-D1184-Z120-3-7419...
  • Page 10: Information On Boards

    The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1184-Z120-3-7419...
  • Page 11: Features

    PCI slots support 3.3 V main and auxiliary voltages. • 1 AGP slot The AGP slot supports the 1x, 2x and 4x AGP mode or GPA memory modules. AGP slot supports 3.3 V main and auxiliary voltages. • 1 AMR slot English - 3 A26361-D1184-Z120-3-7419...
  • Page 12 (16C550 compatible with FIFO). This port does not support the ring indicator signal. • 1 internal WOL interface • 2 external PS/2 interfaces for keyboard and mouse • 2 external USB ports • 1 internal USB interface • Real-time clock/calendar with integrated battery backup 4 - English A26361-D1184-Z120-3-7419...
  • Page 13: Interfaces And Connectors

    4 = USB ports 1 and 2 9b = Audio Line-In 5 = Serial port 1 9c = Audio Micro-In 6 = Parallel port The components and connectors marked are not necessarily present on the system board. English - 5 A26361-D1184-Z120-3-7419...
  • Page 14 12 = Fan 1 (e. g. for the processor) 6 = Connector for control panel and 13 = Power supply monitoring loudspeaker 14 = Cover monitoring The components and connectors marked are not necessarily present on the system board. 6 - English A26361-D1184-Z120-3-7419...
  • Page 15: Temperature Monitoring / System Monitoring

    Display news LED and processed by the BIOS or the application. Cover monitoring: Unauthorized opening of the cover is detected, even when the system is switched off. However, this will not be indicated until the system is operating again. English - 7 A26361-D1184-Z120-3-7419...
  • Page 16: Hard Disk Connection

    The LAN RJ45 connector is equipped with a yellow and a green LED (light emitting diode). 1 = Yellow indicator 2 = Green indicator Green a connection exists (e. g. to a hub). Yellow Link Mode: the LAN connection is active. WOL mode: a Magic Packet is being received. 8 - English A26361-D1184-Z120-3-7419...
  • Page 17: Possible Screen Resolution

    D, A, B, C PCI bus slot 3 A, B, C, D PCI bus slot 4 B, C, D, A PCI bus slot 5 A, B AGP slot USB controller LAN controller Graphics processor SMBus AC'97 Audio English - 9 A26361-D1184-Z120-3-7419...
  • Page 18: Settings With Switches And Jumpers

    BIOS Setup must be disabled (in menu Security, the field Diskette Write must be set to Enabled). The floppy disk drive is write-protected. Read, write and delete floppy disks is possible (default setting). 10 - English A26361-D1184-Z120-3-7419...
  • Page 19: Add-On Modules

    8 = AMR slot 3 = Voltage indicator LED 9 = PCI slots 1, 2, 3, 4, 5 4 = Location bank 1 for main memory 10 = AGP slot 5 = Location bank 2 for main memory English - 11 A26361-D1184-Z120-3-7419...
  • Page 20: Installing / Removing Processor

    The angled corner of the processor may be covered by the heat sink. In this case let yourself be guided by the marking in the rows of pins on the underside of the processor. Ê Push the lever back down so that it snaps into place (5). 12 - English A26361-D1184-Z120-3-7419...
  • Page 21: Upgrading Main Memory

    At the same time flip the lateral holders upwards until the memory module snaps in place (2). Removing a memory module Ê Flip the holders to the right and left of the location outwards (1). Ê Pull the memory module out of its location (2). English - 13 A26361-D1184-Z120-3-7419...
  • Page 22: Upgrading Gpa Memory

    5 V auxiliary voltage of at least 1 A. If the system board was not already incorporated in a device when you bought it you must check whether your power supply can provide the auxiliary voltage. You may find further information in the supplied description of the network board. 14 - English A26361-D1184-Z120-3-7419...
  • Page 23: Replacing The Lithium Battery

    Brukte batterier kasseres i henhold til fabrikantens instruksjoner. Ê Lift the contact (1) a few millimeters and remove the battery from its socket (2). Ê Insert a new lithium battery of the same type in the socket (3). English - 15 A26361-D1184-Z120-3-7419...
  • Page 24: Glossary

    Graphics and Memory Controller Universal Serial Bus Graphics Performance Video Graphic Adapter Accelerator Inter Integrated Circuit Wake On LAN IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security 16 - English A26361-D1184-Z120-3-7419...
