HUSKY LINERS 5730 Installation Instructions

95-02 CHEVROLET ZR2 S-10 PICKUP / GMC SONOMA HIGHRIDER TRUCK
REAR MUD GUARD SET
INSTALLATION INSTRUCTIONS
Install Paint Protection Film before mud guards (see other side)
Please read instructions thoroughly before installation.

Tools Required:

1/8" drill bit / Drill
Wrench (varies depending on vehicle)
Center punch / Hammer
Short Phillips screwdriver
Marking utensil (fine tip marker, grease pencil, etc.)
NOTE: It may be necessary to remove the wheels depending on the tools being used for installation.
1. Clean and degrease the mud guard location area on the fender before installation.
2. Using a Wrench, remove existing fastener from location A (see figure 1) (fastener type varies from vehicle to vehicle).
3. Attach mud guard to fender with existing fastener at location A, check fit and level before tightening.
4. Using mud guard as a template, mark, center punch, and drill 1/8" holes at locations B and C.
5. Attach mud guard to fender with #10 screws at locations B and C.

PAINTING INSTRUCTIONS

1. Clean mud guard with a soap and water solution to remove dirt and other contaminates.
2. Sand painting surface with 320 grit sand paper.
3. Apply a coating of flexible primer-adhesion promoter.
4. Apply a flexible paint as directed by the paint manufacturer.

Package Contents

Driver & passenger side mud guard
1" #10 screws (qty. 4)
Paint protection film
Instruction sheet
5730
PART NO.
5730 Rear Instructions.doc
Rev: 0
