HUSKY LINERS 5777 Installation Instructions

REAR MUD GUARD
INSTALLATION INSTRUCTIONS
Please read instructions thoroughly before installation.
Tools Required
1/8" drill bit / Drill
•
Center punch / Hammer
•
Short Phillips screwdriver or drill attachment
•
NOTE: It may be necessary to remove the wheels depending on the tools being used for installation.
1. Clean and degrease the mud guard location area on the fender before installation.
2. Remove existing fasteners from locations A and B (Figure 1).
3. Attach mud guard to rear fender with a #10 screw and washer, thru mud guard, fender / fender liner and into a U-clip on the
backside of the fender liner at locations A and B (Figures 1 & 2). Check fit and level before tightening.
4. Using mud guard as a template, mark and drill an1/8" hole at location C and install a #10 screw and washer.
PAINTING INSTRUCTIONS
1. Clean mud guard with a soap and water solution to remove dirt and other contaminates.
2. Sand painting surface with 320 grit sand paper.
3. Apply a coating of flexible primer-adhesion promoter.
4. Apply a flexible paint as directed by the paint manufacturer.
Package Contents
Driver & passenger side rear mud guard
•
#10 screw (qty. 6)
•
Washers (qty. 6)
•
U-clip (qty. 6)
•
Primer Ampoule (qty. 1)
•
Instruction sheet
•
5777
PART NO.
