Generac Power Systems Centurion 004692-0 Installation And Owner's Manual page 39

ITEM PART NO. QTY. DESCRIPTION
1 0A9947E 1 CIRCUIT BREAKER 30 X 2 240V SQD
QOU230 (7KW)
0A9947G 1 CIRCUIT BREAKER 40 X 2 240V SQD
QOU240 (8.5KW)
0A9947F 1 CIRCUIT BREAKER 50 X 2 240V SQD
QOU250 (12KW)
0A9947C 1 CIRCUIT BREAKER 60 X 2 240V SQD
QOU260 (13KW)
2 0A18010SRV 1 ASSEMBLY, BATTERY CHARGER ENGINE
3 0830490SRV 1 ASSEMBLY, POTTED REGULATOR
4 0C2174 1 RELAY, 12V 25A SPST
5 075210A 1 BLOCK 1 POSITION
6 0D3062 4 HEX STAND-OFF #6-32 x 3/8"
7 0D8615 1 ASSEMBLY, HOME STANDBY CONTROLLER
8 032300 2 HOLDER, FUSE
9 022676 1 FUSE, 15AMP X AGC15
10 033873 1 SWITCH, ROCKER
11 0D5045 1 DIN RAIL
12 023484E 1 SNAP BUSHING SB-687-8
13 075476 2 SCREW PPHM M4-0.7 x 16mm
14 022264 6 WASHER LOCK M4
15 051715 6 NUT HEX M4-0.7
16 043182 4 WASHER LOCK M3
17 043181 4 SCREW PHM M3-0.5 x 10mm
18 0D8443 1 DECAL, CONTROL PANEL (NOT SHOWN)
19 054502 1 CIRCUIT BREAKER 3 X 1 ETA 46-500-P
20 0D8438 1 CONTROL, PANEL BOTTOM
21 075235 4 SCREW HHC M5-0.8 x 30mm
Section 8 — Exploded Views and Parts Lists
Air-cooled 8.5 kW Generator
Control Panel Assembly – Drawing No. 0D8503-B
ITEM PART NO. QTY. DESCRIPTION
22 0D5240
23 051714
24 0D8502
25 0A1661
26 0D8441
27 074908
28 049226
29 051716
30 0C3910
31 022507
32 099727
33 046689
34 063617
35 075475
36 022985
37 0D8439
38 092036
39 045770
40 0C7171
41 0D3700
43 0A2311
44 0A1658
45 022473
46 038750
47 022097
48 049813
49 031879
1 SWITCH, SPDT ON-MOM-ON
4 NUT HEX M3-0.5
1 NEUTRAL ISOLATOR
2 RIVET POP .156 X .160-.164/#20
1 HARNESS, CONTROL PANEL WIRE (NOT
SHOWN)
4 SCREW TAPTITE, M5-0.8 x 10 BP
6 WASHER LOCK M5
6 NUT HEX M5-0.8
1 TRANSFORMER
2 SCREW HHC 1/4"-20 x 1/2"
1 FUSE 5A X AGC5
1 TERMINAL STRIP
1 RELAY PANEL 12VDC DPDT 10A 240VAC
4 SCREW PPHM M4-0.7 x 10mm
2 WASHER FLAT #6
1 COVER, CONTROL PANEL COMPONENT
8 SCREW PPHMS/LW #6-32 x 1/4"
2 SCREW HHC M5-0.8 x10mm
1 COVER, CONTROL PANEL
10 NUT FLANGE M6-1.0 NYLOCK
1 SCREW SWAGE 1/4"-20 x 1"
2 LOCKWASHER SPECIAL 1/4"
3 WASHER FLAT 1/4"
1 SCREW HHC M6-1.0 x 30mm
3 WASHER LOCK M6-1/4"
1 NUT HEX M6-1.0
4 WASHER FLAT #4
Generac Power Systems, Inc. 37
®
