NX4 (fixed installation)
4mm, 2,000 NIT, true black indoor LED display
The new visual standard
Experience the new visual standard in indoor LED displays—Barco's allnew
NX4. With its revolutionary black LED, the NX4 delivers more contrast and
deeper black levels than any other product on the market.
But the new Black LED is only one element that makes the NX4 unique. Key
advances in base materials, mechanical design and color processing have
raised the bar of LED displays to new heights of image quality.
Key benefits:
⋅ Phenomenal black levels
⋅ 4,000:1 contrast ratio
⋅ 2,000 NIT brightness
⋅ 16bit color processing
⋅ Replaceable shaders
⋅ Consistent uniformity
⋅ High Definitionready
⋅ Modular creativity
Advertisement
Related Manuals for Barco NX-4
Summary of Contents for Barco NX-4
- Page 1 NX4 (fixed installation) 4mm, 2,000 NIT, true black indoor LED display The new visual standard Experience the new visual standard in indoor LED displays—Barco’s allnew NX4. With its revolutionary black LED, the NX4 delivers more contrast and deeper black levels than any other product on the market. But the new Black LED is only one element that makes the NX4 unique. Key advances in base materials, mechanical design and color processing have raised the bar of LED displays to new heights of image quality.
- Page 2 Width: 448mm (17.6") Height: 504mm (19.8") Depth: 210mm (8.27") Weight / Tile 12.9 kg IP rating Indoor use only Processing 16 bit/color Colors 281 trillion Refresh rate 3,200Hz Foot buildup Max. 12 tiles high Truss buildup Max. 15 tiles high Link interface NNI interface (HDMI connector) Max link length 10m (with Barco HDMI cable) Interfaces 4x HDMI link 1x USB (diagnostic) Max power cascade connection 8 tiles Serviceability Front and back (tools required for front) Operating temperature 040°C Storage temperature 20 60°C Operational humidity 3585% Storage humidity 1090% Source compatibility CVBS, YC, YUV, RGB, DVI (Single and Dual link , up to 2048x1536) SDI. HDSDI, Dual link HDSDI Operatable digitizer DX700 (with NNI output card)
