R E P A I R P A R T N A M E S A N D N U M B E R S
INDIVIDUAL PARTS
ITEM PART# DESCRIPTION
2 Q162 1.5 Amp Fuse
3 Q222 Control Board (Single Operator)
4 Q223 Control Board (Master/Second)
5 Q310 Surge Protection (Single)
6 Q311 Surge Protection
(Master/Second)
7 Q227P Plastic Control Board Box
(Nuts and Bolts for Battery Rack)
8 K33-51206-315 Radio Receiver Board
9 Q230 Steel Bracket Mounting Plates (2)
10 K23-19380-2 Reset Switch and Harness
11 Q232 Bottom Washer and Nut
(For Traveler Carriage)
12 Q233 Bolt, Bushing, Nut
(Fits Rear Mount of Operator)
13 Q234 Bracket/Rod
14 Q239 Limit Switch Harness
(Wires and 4 Limit Switches)
16 Q243 8 Amp Fuse - Single
17 Q257 Replacement Key/Lock
(Operator Made Post 3/14/99)
18 Q258 Fuse - 2 Amp - Single
19 Q259 Fuse - 3 Amp - M/S
20 Q260 15 Amp Fuse (2)
21 Q262 Harness-Motor (Operator Cord)
with Flex Conduit
22 Q300 Traveler Carriage
23 Q301 Arm Cover Set
(Top and Bottom Aluminum)
24 Q302 Arm End Caps (Set)
25 Q303 Arm Cover Gaskets (Set)
26 Q404 UL Audio Alarm
27 Q029 Limit Switch (1)
28 ABTMIR Plastic Rack and 2 Batteries
29 APOW3 34 Vdc 1.7 A Transformer
ITEM PART#
K94-50838
29-NP712
K77-50983
Q306
41
NOT SHOWN
DESCRIPTION
6 Conductor Wire Cable per ft.
Battery
40' Cable w/Connectors
and Junction Box for M/S
applications
Arm Upgrade Kit
Traveler Carriage
Arm Cover Set
Arm Cover Gaskets
Limit Switch Harness
