Table Of Contents - Chamberlain MIRACLE-ONE Owner's Manual

WARNING
Mechanical
WARNING
CAUTION
When you see these Safety Symbols and Signal Words on the
following pages, they will alert you to the possibility of serious
injury or death if you do not comply with the warnings that
accompany them. The hazard may come from something
mechanical or from electric shock. Read the warnings carefully.
When you see this Signal Word on the following pages, it will alert
you to the possibility of damage to your gate and/or the gate
operator if you do not comply with the cautionary statements that
accompany it. Read them carefully.
IMPORTANT NOTE
• BEFORE attempting to install, operate or maintain the operator,
you must read and fully understand this manual and follow all
safety instructions.
• DO NOT attempt repair or service of your residential gate
operator unless you are an Authorized Service Technician.
T A B L E O F C O N T E N T S
Electrical
SPECIFICATIONS AND WARNINGS
Carton Inventory and . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Model Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Suggested Entrapment Protection Device Locations . . . . . . . . . 6
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
INSTALLATION
Installation Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mounting Operator that Opens to the Outside . . . . . . . . . . . . . . 9
Mounting Operator that Opens to the Inside. . . . . . . . . . . . . . . 10
Mounting Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Mounting Control Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mounting Operator(s) to Control Box . . . . . . . . . . . . . . . . . . . . 14
Control Board Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Surge Suppressor Connections . . . . . . . . . . . . . . . . . . . . . . 16-17
WIRING
Earth Ground Rod Installation . . . . . . . . . . . . . . . . . . . . . . . . . 18
Wiring operator(s) to Control Board. . . . . . . . . . . . . . . . . . . . . 19
DC Power Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
UL Alarm Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Burglar Alarm Connections (House Alarm and Proximity Switch) . . . . 21
Wiring Additional Inputs (Strike Input). . . . . . . . . . . . . . . . . . . 22
24 Vdc External Loop Detector Wiring . . . . . . . . . . . . . . . . . . . 23
Entrapment Protection Devices (Non-Contact Sensors) . . . . . . 24
Maglock or Solenoid Connection . . . . . . . . . . . . . . . . . . . . . . . 25
ADJUSTMENTS
Set Gate Opening Direction. . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Limit Switch Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Adjusting Reverse Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Positive Stop Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
315 MHz Radio Receiver Programming . . . . . . . . . . . . . . . . . . 29
Close Delay for Overlapping Gates . . . . . . . . . . . . . . . . . . . . . . 30
MAINTENANCE AND OPERATION
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Built-In Reset Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Audio Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Emergency Manual Release . . . . . . . . . . . . . . . . . . 33
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Wiring Schematics (Single and Master/Second) . . . . . . . . . 36-39
REPAIR PARTS
Repair Part Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Part Names and Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ACCESSORIES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
HOW TO ORDER REPAIR PARTS
WARRANTY POLICY
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
INSTALLATION CHECKLIST
3 1
. . . . . . . . . . . . . . . . . . 43
. . . . . . . . . . . . . . . . . . . . . . . 44
