3.1 SoftMenu Setup

The SoftMenu utility is ABIT's exclusive and ultimate solution in programming the CPU operating
speed. All the parameters regarding CPU FSB speed, multiplier factor, the AGP & PCI clock, and
even the CPU core voltage are all available at your fingertips.
AMD Athlon(tm) 64 Processor 3800+
Frequency
CPU Operating Speed
X - CPU External Clock(MHz)
X - PCIe Clock
X - Multiplier Factor
Voltages Control
X - CPU Core Voltage
X - DDRII Voltage
X - DDRII Reference Voltage
X - Chipset Core Voltage
X - SB Core AUX Voltage
X - Hyper-Transport Voltage
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Brand Name
This item displays the CPU model name.
Frequency
This item displays the CPU internal clock speed.
CPU Operating Speed
This item displays the CPU operating speed according to the type and speed of your CPU. You
can also select the [User Define] option to enter the manual option.
User Define:
※ The wrong settings of the multiplier and external clock in certain circumstances
may cause CPU damage. Setting the working frequency higher than the PCI
chipset or processor specs, may cause abnormal memory module functioning,
system hangs, hard disk drive data lose, abnormal functioning of the VGA card,
or abnormal functioning with other add-on cards. Using non-specification
settings for your CPU is not the intention of this explanation. These should be
used for engineering testing, not for normal applications.
3-2
Phoenix – Award BIOS CMOS Setup Utility
