Marantz PMD570 Owner's Manual Addendum
Professional installation solid state recorder rs-232 serial control addendum
Hide thumbs
Also See for PMD570:
- User manual (55 pages) ,
- User manual (55 pages) ,
- Service manual (72 pages)
Subscribe to Our Youtube Channel
Related Manuals for Marantz PMD570
Summary of Contents for Marantz PMD570
-
Page 1: Owners Manual
PMD570 Professional Installation Solid State Recorder RS-232 Serial Control Addendum for Owners Manual... - Page 2 RS-232C Control Windows Application • control all functions of PMD570 • setup/preset menu An RS232 Windows Application for the PMD570 is • read/write settings to/from PMD570 available for free download (see www.d-mpro.com to • save settings as text file, download). The Application lets you control and setup •...
- Page 3 Transmit Data Receive Data 4. When data output finishes, the host sets RTS to H. Transmit Data Receive Data 5. The PMD570 checks if CTS is H and sets RTS to L. Not Connected Not Connected Ground Ground Not connected...
- Page 4 CR (0x0d) is added as the data packet delim- iter. Example: Status Information code "Door open" Status Request Commands from the host are received (ASCII code @0DS01CR) by the PMD570, then the status information code is transmitted to the host. 0x40 0x30 0x44...
- Page 5 Table of Control command codes continued M.Level (XX) ......“@0CLXX” + CR Fast Reverse Stop << ......“@0235001” + CR Play Mode* Fast Forward Start >> ......“@02352” + CR Normal ........“@0PMOF” + CR Fast Forward Stop >> ......“@0235201” + CR Repeat All ........
- Page 6 Date Form ............“@0?DF” + CR When a Status Request Command from the host is M/D/Y ............“@0DFDM” + CR received by the PMD570, the PMD570 sends the D/M/Y ............“@0DFMD” + CR Status Information to the host. When the PMD570 RecFormat Channels ....
