Refrigerator
Do not install refrigerator where temperature
will be below 60°F (16°C) because it will not
location
run often enough to maintain proper
temperatures.
Clearances
If the refrigerator is to be installed in a corner,
allow 2 (51 mm) between the hinges of the
refrigerator and the wall to assure a 90° door
opening capability.
Leveling
This model has 4-point leveling. All 4 corners
are supported by leveling legs. The front wheels
are non-adjustable; they are only used for
positioning the unit.
• To level the back of the unit, turn hex nut
• To level the front of the unit, use a 1
• Turn hex nut or front leveling leg clockwise
See the Installation Instructions (Pub. No.
49-6983) for complete directions.
located above the front wheels.
end wrench and adjust the leveling legs.
to raise the unit, counter-clockwise to lower
the unit.
Preparation
Do install it on a floor strong enough to support
a fully loaded refrigerator.
No other clearances at top, sides or back are
required.
Hex Nut
1
open
4
Bottom Mount Refrigerator
Leveling Leg
Wheel
15
