June 2012
2.2
Parts and function
Figure 2-2:
1
Field connection indicator light
2
Power indicator light
3
USB port
4
Fieldbus device connection socket
(*) See the following Indicator Light Scenarios table.
The USB Fieldbus Interface
(*)
(*)
Indicates the fieldbus device connection status
Indicates the power mode of the interface
B-type receptacle, compliant with USB 1.1 and 2.0
specifications
Banana-type connection, compatible with the lead set
provided
User's Manual
7
