June 2012
4. Click OK to acknowledge the warning.
5. Click the Apply button.
6. Select Yes to restart the USB FF HSE Server and use the new setting.
4.4
Commissioning fieldbus devices
Commissioning sets the fieldbus device address to a valid permanent address
and sets the device tag to a valid string.
Notes
You need to commission fieldbus devices first before you can use them with AMS Device
Manager.
Fieldbus devices on a live segment cannot be commissioned.
1. Launch the Fieldbus Device Configuration utility.
2. Under the USB Fieldbus Interface icon, select the fieldbus device you
want to configure.
A connected fieldbus device or segment should be powered by an
external power source or be provided power by the Fieldbus Device
Configuration utility for it to be detected.
3. Optionally, select a permanent device address from 20 to 38. Otherwise,
the first available address is assigned.
4. Optionally, enter a device tag.
5. Click the Commission button.
User's Manual
25
