8 Specifications

8.1 Technical Specifications

8.1.1 Autopilot instrument

Dimensions:
Weight:
Enclosure:
Instrument cable:
Power supply:
Power consumption:
Current consumption:

8.1.2 Servo Unit A-1500

Dimensions:
Weight:
Enclosure:
Cable:
Power supply:
Power consumption:
Current consumption:
Max. motor output drive:
Output:

8.1.3 Servo Unit A-1510

Dimensions:
Weight:
Enclosure:
Cable:
Power supply:
Power consumption:
Current consumption:
Max. motor output drive:
Output:

8.1.4 Rudder Angle Transmitter

Dimensions:
Transmitter arm:
Ball joint linkage arm:
Weight:
Enclosure:
Cable:
Power supply:
Power consumption:
Current consumption:
Rudder angle:
Resistance:
Life:
Temperature range:
The above products have the same temperature range.
Storage:
Operation: -10°C to +70°C. (14°F to 158°F)
SPECIFICATIONS
110 x 110 x 23 mm (4.3 x 4.3 x 0.9")
260 g (9.17 oz)
Water proof
0.4 m (16")
12 V DC (10-16 V). The instrument is polarity protected.
0,08 W. At max lighting 0.8 W.
7 mA (at 12V). At max lighting 70 mA (at 12V).
220 x 145 x 55 mm (8.7 x 5.7 x 2.2")
800 g (28.2 oz)
Splash proof
8m (26ft) Nexus cable
12 or 24 V DC (10-40 V)
4 W, plus drive unit demand
0,3A (at 12V)
25 A
NMEA 0183 compass, RAI
160 x 110 x 38 mm (8.7 x 5.7 x 2.2")
420 g (14.8 oz)
Splash proof
8m (26ft) Nexus cable
12 or 24 V DC (10-30 V)
3 W, plus drive unit demand
0,3A (at 12V)
15 A
NMEA 0183 compass, RAI
70 x 70 x 75 mm (2.7 x 2.7 x 3.0")
120mm (4.7") long
2 arms, each 320mm (12,6") long
170 g (6 oz) (without cable and linkage arm)
Water proof
15m (50ft), 3-lead.
From Servo Unit
2,5mW
0,5mA
± 55°
10k
50 million cycles dither
-30°C to +80°C.( -22°F to 176°F)
29
