1

Part specifications

Nexus Wind Data is delivered with all parts for mounting. Check prior to
installation.
Wind Data instrument
Qty. Description
1 Instrument, Nexus Wind Data
1 Instrument front cover
1 Drill template
1

Installation and user manual

1 Warranty card
1 National distributors list
1 Power cable, red and black, 3 m (9 ft)
5 Extra wire protectors, 0,25 mm (1/100")
5 Extra wire protectors, 0,75 mm (1/32")
4 Mounting screws for the instrument
4 Round rubber covers
1 Tube of silicon grease
1 Connection cover
2 4-pol screw terminal
Additional in Wind Data complete with transducer
1 Wind transducer Nexus
1 Mast top cable. 25m (83 ft)
3 Mounting screws for mast bracket
1 Mast head bracket
Registering of this product
Once you have checked that you have all the listed parts, please take
time to fill in the warranty document and return it to your national
distributor.
By returning this document, it will assist your distributor to give you
prompt and expert attention, in the event of your experiencing difficulties
with this product. Keep your proof of purchase. Also, your details are
added to our customer database so that you automatically receive new
product catalogues as and when they are released.
PART SPECIFICATIONS
4
Reference
1
2
3
4
5
6
7
8
8
9
9
9
9
9
10
11
12
13
