7.3 Nexus Network error messages with cause and remedy

If an error message [Err #] is displayed, an error has been detected by the Nexus Network.
The message can assist you to diagnose the cause and remedy the error.
To escape from an error message, press any push-button. If not possible to escape, reset
power (turn off and on again), then make the remedy if suggested below.
Note! For errors marked with [*], contact your national distributor to return the unit for
rectification.
No. Message and cause
01 Activated watchdog timeout.
02 Nexus Network data frames are missing.
03 No data received within approx. 10 sec.
04 EEPROM read.
05 EEPROM write.
06 RAM memory error.
07 Auto-log full, in GPS Compass.
08 Break reset.
09 EEPROM auto initiation, or NMEA
transmit fail. (Nexus Server only).
10 Range error, depending on wrong input
e.g. 17 70' = too many minutes.
11 Remote control setup error. Command
can not be executed.
12 No response from navigator.
13 Waypoint not defined.
14 Impossible command when used with an
external NMEA navigator.
15 Impossible command when in Autopilot
mode.
16 Auto-deviation is not possible.
17 Auto-deviation check failed.
18 Auto-deviation. Function denied.
19 Auto-deviation failure.
20 GPS to CPU communication error.
21 GPS acquisition failure (time out).
22 CPU to GPS communication error.
23 DGPS (RTCM) data ignored.
24 GPS bad fix, no fix position (time expired
at one-fix).
FAULT FINDING
Remedy
Reset power.
Check connections and setup.
Check connections.
Reset power.
Reset power.
Reset power.
Clear Auto-log memory.
Reset power.
Reset power.
Correct input format..
Check connections and settings.
Check navigator connection and set-
tings.
Define a waypoint.
Use only possible command.
Use only possible commands.
Check for extreme magnetic field, up-
side down mounting of transducer or
wrong transducer type setting.
1¼ turn not completed or extreme
magnetic disturbance.
Function denied since compass is
busy with the auto-deviation routine.
Error larger than 1.5 . The boat
probably hit a wave during the turn.
Reset power.
Maximum allowed time for searching
satellites. E.g. when try to navigate
indoors. Check GPS antenna loca-
tion.
Reset power.
Change the DGPS (RTCM) setting.
Check GPS antenna location.
