Nexus AUTOPILOT Installation And Operation Manual page 33

Art. No. Nexus Analog Instruments
20550-2 Steer Pilot analog
20550-1 Wind Angle analog
20550-6 Compass analog
20550-3 Speed analog, 0-16 KTS
20550-4 Speed analog, 0-50 KTS
20550-5 Depth analog, 0-200 m
20550-7 Depth analog, 0-600 FT
20550-8 Speed Trim analog, 20% - 0 - 20%
20550-9 Rudder Angle analog, 50 - 0 - 50
Art. No. Nexus Autopilot
21035 Servo Unit A-1500
21035-2 Servo Unit A-1510
21036 Rudder angle transmitter
21134 Pumpset 12V PF-0,3, for hydraulic steering
21341 Pumpset 12V PF-0,3 with solenoid, for mechanical steering
21136-2 Cylinder SP-20, stroke 200 mm
Art. No. Other Nexus Accessories
19841 Maxi Repeater yellow digits, NMEA repeater
19941 Maxi Repeater red digits, NMEA repeater
69999 Mast bracket Maxi, for two Maxi repeaters
69995 Mast bracket XL, for Multi XL and standard Nexus
110x110
21556 Connection box Nexus Network
21453 Connection box Wind Data and Compass incl. 6 m (19 ft) cable
21248-1 PC Interface FD (Full Duplex) / NMEA with 1 m (3.3 ft) cable and a 3½"disc.
20438 Instrument cover Nexus instruments 110 x 110 mm
20443 Nexus extension cable, per meter
21266-8 Nexus cable 8 m (26 ft) with wire protectors at each end
20594 Nexus mast cable 25 m (82 ft)
18129 Instrument panel for up to 6 Nexus 110x110 mm instruments
19763 Remote push button for extern MOB or Trim function
20081 External alarm buzzer, for Nexus Server
19038 Internal mounting kit for depth transducer
19216 Through hull fitting - bronze
21154 Paddlewheel blue with axle, high speed 0-50 kts
67400-15 Mast top adapter 15° aluminium
18500 Through deck connector 7-pole
18501 Through deck connector 4-pole
20966 Connector 4-pole
SPECIFICATIONS
