Page 1: User Manual
1000 Series Gigabit Media Converter & Industrial Gigabit Ethernet Switch User Manual & Installation Guide (Revised 2011-09-28) - Page 2 80 for 80km max. fiber segment length 1003GX2-B SFP (Mini-GBIC) Fiber Transceivers: NTSFP-SX (LC Style Connector, up to 550m) NTSFP-LX-10 (LC Style Connector, up to 10km) NTSFP-LX-40 (LC Style Connector, up to 40km) NTSFP-LX-80 (LC Style Connector, up to 80km) (Revised 2011-09-28)
- Page 3 In no event shall N-TRON Corp. be liable for any incidental, special, indirect or consequential damages whatsoever included but not limited to lost profits arising out of errors or omissions in this manual or the information contained herein.
-
Page 4: Electrical Safety Warnings
Do not operate the equipment in the presence of flammable gasses or fumes. Operating electrical equipment in such an environment constitutes a definite safety hazard. WARNING: If the equipment is used in the manner not specified by N-TRON Corp., the protection provided by the equipment may be impaired. - Page 5 LASER SAFETY (1002MC and 1003GX2 Models) CAUTION: CLASS 1 LASER PRODUCT. Do not stare into the laser!) (Revised 2011-09-28)
- Page 6 ENVIRONMENTAL SAFETY WARNINGS WARNING: Disconnect the power and allow to cool 5 minutes before touching. 1000 Series Industrial Gigabit Ethernet Switches The 1000 Series Unmanaged Industrial Gigabit Ethernet Switches support high speed layer 2 switching between ports. This series of switches are housed in a ruggedized aluminum enclosure, and provide Category-5 compliant 10/100/1000Base-T connections for high performance network design, and hub/repeater upgrades.
-
Page 7: Package Contents
PACKAGE CONTENTS Please make sure the package contains the following items: 1000 Series Media Converter or Ethernet Switch Product CD Contact your carrier if any items are damaged. UNPACKING Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage claims with the carrier. - Page 8 URMK 1000-PM Most N-Tron™ products are designed to be mounted on industry standard 35mm DIN rail. However, DIN rail mounting may not be suitable for all applications. Our Universal Rack Mount Kit (P/N: URMK) may be used to mount the 1000 Series enclosures to standard 19" racks, and our Panel Mount Assembly (P/N: 1000-PM) may be used to mount the 1000 Series enclosures to a panel or any other flat surface.
-
Page 9: Front Panel
FRONT PANEL From Top to Bottom: Green LED lights when Power is connected LNK/ACT Link/Activity LED SPD1000 1000 Speed LED LEDs: The table below describes the operating modes: Color Description Power is Applied. Power is OFF. Link established, no Activity on cable. BLINKING Link established, Activity on cable LNK/ACT... - Page 10 DC Voltage sources. Use wire sizes of 12-24 gauge. The power cord should be limited to less than 10 meters in order to ensure optimum performance. Recommended 24V DC Power Supplies, similar to: 100-240VAC: N-Tron NTPS-24-1.3, DC 24V/1.3A (Revised 2011-09-28)
- Page 11 (i.e. CE) are obtained when the N-Tron switch chassis is connected to earth ground via a drain wire. Some N-Tron switches have metal din-rail brackets that can ground the switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with optional plastic brackets if isolation is required.
-
Page 12: Connecting The Unit
~ 2X. 3. Verify that Link LEDs are ON for both ports. 4. Verify cabling used between stations. 5. Verify that cabling is Category 3 or greater for 10Mbit Operation. SUPPORT Tel: (251)-342-2164 FAX: (251)-342-6353 http://www.n-tron.com N-TRON_Support@n-tron.com (Revised 2011-09-28) -
Page 13: Fcc Statement
FCC STATEMENT This product complies with Part 15 of the FCC-A Rules. Operation is subject to the following conditions: (1) This device may not cause harmful Interference (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 14 1002MC - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: 1.0” (2.54 cm) Width: 3.61” (9.165 cm) Depth w/ typical SFP installed: Weight: 0.70 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 200mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.8 ms max.
- Page 15 Gigabit Fiber Transceiver (SFP) Characteristics 550m* with 50/125 µm Fiber Length 10km** 40km** 80km** 275m @ 62.5/125μm TX Power Min -9.5dBm -9.5dBm -2dBm 0dBm RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm Wavelength 850nm 1310nm 1310nm 1550nm Assumed Fiber Loss 3.5 to 3.75 dB/km 0.45 dB/km 0.35 dB/km 0.25 dB/km...
- Page 16 1003GX2 - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: 1.0” (2.54 cm) Width: 3.61” (9.165 cm) Depth w/ typical SFP installed: Weight: 0.7 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 200mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.8 ms max.
- Page 17 Gigabit Fiber Transceiver (SFP) Characteristics 550m* with 50/125 µm Fiber Length 10km** 40km** 80km** 275m @ 62.5/125μm TX Power Min -9.5dBm -9.5dBm -2dBm 0dBm RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm Wavelength 850nm 1310nm 1310nm 1550nm Assumed Fiber Loss 3.5 to 3.75 dB/km 0.45 dB/km 0.35 dB/km 0.25 dB/km...
- Page 18 1005TX - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: Width: 1.0” (2.54 cm) 3.61” (9.165 cm) Depth: Weight: 0.70 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 230mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.61 ms max.
- Page 19 Regulatory Approvals: Safety: UL Listed per ANSI/ISA-12.12.01-2007 (US and Canada) and listed for use in Class I, Div 2, Groups A, B, C, D, T4. EMI: EN61000-6-4, EN55011 - Class A FCC Title 47, Part 15, Subpart B - Class A ICES-003 –...
- Page 20 Responsibility for loss or damage does not transfer to N-TRON until the returned item is received by N-TRON. The repaired or replaced item will be shipped to the customer, at N-TRON’s expense, not later than thirty (30) days after N-TRON receives the product.
