Page 1: User Manual
1000 Series Gigabit Media Converter & Industrial Gigabit Ethernet Switch User Manual & Installation Guide (Revised 2014-01-23) - Page 2 Industrial Gigabit Ethernet Switch Installation Guide 1002MC-SX 1000BaseSX multimode fiber media converter 1002MC-LX-YY 1000BaseLX singlemode fiber media converter 1003GX2-SX 1000BaseSX multimode fiber switch 1003GX2-LX-YY 1000BaseLX singlemode fiber switch 1003GX2-B Custom mix and match 1003GX2 switch 1005TX 5 port gigabit Ethernet switch Where "YY"...
- Page 3 In no event shall N-Tron Corporation be liable for any incidental, special, indirect or consequential damages whatsoever included but not limited to lost profits arising out of errors or omissions in this manual or the information contained herein.
- Page 4 ALERTE : Ne pas utiliser le matériel en présence de gaz ou de vapeurs inflammables. L'utilisation de matériel électrique dans un tel environnement constitue un danger certain. WARNING: If the equipment is used in the manner not specified by N-Tron Corporation, the protection provided by the equipment may be impaired.
- Page 5 WARNING: Do not operate the unit with the end plates removed, as this could create a shock or fire hazard. ALERTE : Ne pas faire fonctionner l'unité avec les plaques d'extrémité retiré, ce qui pourrait créer une décharge électrique ou un incendie. WARNING: Properly ground the unit before connecting anything else to the unit.
- Page 6 ENVIRONMENTAL SAFETY WARNINGS WARNING: Disconnect the power and allow to cool 5 minutes before touching. ALERTE: Déconnectez le câble d'alimentation et laisser refroidir 5 minutes avant de la toucher. 1000 Series Industrial Gigabit Ethernet Switches The 1000 Series Unmanaged Industrial Gigabit Ethernet Switches support high speed layer 2 switching between ports.
-
Page 7: Package Contents
PACKAGE CONTENTS Please make sure the package contains the following items: 1000 Series Media Converter or Ethernet Switch Product CD Contact your carrier if any items are damaged. UNPACKING Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage claims with the carrier. - Page 8 URMK 1000-PM Most N-Tron™ products are designed to be mounted on industry standard 35mm DIN rail. However, DIN rail mounting may not be suitable for all applications. Our Universal Rack Mount Kit (P/N: URMK) may be used to mount the 1000 Series enclosures to standard 19" racks, and our Panel Mount Assembly (P/N: 1000-PM) may be used to mount the 1000 Series enclosures to a panel or any other flat surface.
-
Page 9: Front Panel
FRONT PANEL From Top to Bottom: Green LED lights when Power is connected LNK/ACT Link/Activity LED SPD1000 1000 Speed LED LEDs: The table below describes the operating modes: Color Description Power is Applied. Power is OFF. Link established, no Activity on cable. BLINKING Link established, Activity on cable LNK/ACT... - Page 10 DC Voltage sources. Use wire sizes of 12-24 gauge. The power cord should be limited to less than 10 meters in order to ensure optimum performance. Recommended 24V DC Power Supplies, similar to: 100-240VAC: N-Tron NTPS-24-1.3, DC 24V/1.3A (Revised 2014-01-23)
- Page 11 (i.e. CE) are obtained when the N-Tron switch chassis is connected to earth ground via a drain wire. Some N-Tron switches have metal din-rail brackets that can ground the switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with optional plastic brackets if isolation is required.
-
Page 12: Connecting The Unit
~ 2X. 3. Verify that Link LEDs are ON for both ports. 4. Verify cabling used between stations. 5. Verify that cabling is Category 3 or greater for 10Mbit Operation. SUPPORT Tel: (251)-342-2164 FAX: (251)-342-6353 http://www.n-tron.com N-TRON_Support@n-tron.com (Revised 2014-01-23) -
Page 13: Fcc Statement
FCC STATEMENT This product complies with Part 15 of the FCC-A Rules. Operation is subject to the following conditions: (1) This device may not cause harmful Interference (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 14 1002MC - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: 1.0” (2.54 cm) Width: 3.61” (9.165 cm) Depth w/ typical SFP installed: Weight: 0.70 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 200mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.8 ms max.
- Page 15 Gigabit Fiber Transceiver (SFP) Characteristics 550m* with 50/125 µm Fiber Length 10km** 40km** 80km** 275m @ 62.5/125μm TX Power Min -9.5dBm -9.5dBm -2dBm 0dBm RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm Wavelength 850nm 1310nm 1310nm 1550nm Assumed Fiber Loss 3.5 to 3.75 dB/km 0.45 dB/km 0.35 dB/km 0.25 dB/km...
- Page 16 1003GX2 - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: 1.0” (2.54 cm) Width: 3.61” (9.165 cm) Depth w/ typical SFP installed: Weight: 0.7 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 200mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.8 ms max.
- Page 17 Gigabit Fiber Transceiver (SFP) Characteristics 550m* with 50/125 µm Fiber Length 10km** 40km** 80km** 275m @ 62.5/125μm TX Power Min -9.5dBm -9.5dBm -2dBm 0dBm RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm Wavelength 850nm 1310nm 1310nm 1550nm Assumed Fiber Loss 3.5 to 3.75 dB/km 0.45 dB/km 0.35 dB/km 0.25 dB/km...
- Page 18 1005TX - KEY SPECIFICATIONS Physical 4.0” (10.16 cm) Height: Width: 1.0” (2.54 cm) 3.61” (9.165 cm) Depth: Weight: 0.70 lbs (0.32 kg) DIN Rail: 35 mm Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 230mA max. @ 24VDC (Steady State) Inrush Current: 13 Amp/0.61 ms max.
- Page 19 Regulatory Approvals: Safety: For use in Class I, Division 2, Groups A, B, C and D Hazardous Locations. UL 508, Industrial Control Equipment. ANSI/ISA-12.12.01-2013 for use in Class I and II, Division 2 and Class III Divisions 1 and 2 Hazardous (Classified) Locations Groups A, B, C, D.
- Page 20 Responsibility for loss or damage does not transfer to N-TRON until the returned item is received by N-TRON. The repaired or replaced item will be shipped to the customer, at N-TRON’s expense, not later than thirty (30) days after N-TRON receives the product.
