Summary of Contents for Clarke LOGBUSTER II
- Page 1 LOGBUSTER II LOGBUSTER II (Electric Log Splitter) Part No. 3402010 OPERATING & MAINTENANCE INSTRUCTIONS 0201...
- Page 2 FEATURES The Logbuster II is a portable log splitter, equipped with electric motor. The various parts of the machine are shown in fig.1. 6 - Foot...
-
Page 3: Specifications
Do not attempt to split a log for longer than 5 seconds WARNING: THE LOGBUSTER II HAS BEEN DESIGNED AND MANUFACTURED TO SPLIT LOGS OF THE SIZES RECOMMENDED. USE OF THE MACHINE FOR... -
Page 4: Safety Rules
GENERAL SAFETY RULES WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property may result. - Page 5 • Never attempt to cut two logs at once; one may be ejected with possibly serious damage. • Split wood in the direction of the grain. Do not attempt to split a piece of wood across the grain as this could seriously damage the machine. •...
-
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: THIS MACHINE MUST BE EARTHED. This product is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, electrical supply. Should the plug need changing at any time, ensure that a plug of identical specification is used.IMPORTANT: The wires in the mains lead should be wired up in accordance with the following colour code: Green &... -
Page 7: Operation
ASSEMBLY Before operating the Logbuster, it is necessary Fig.5 to fit the wheels on to the axle. Thread the wheel (12, Fig. 5) on to the axle (11), secure it using the special washer (13), so that the outer rim of the washer faces outwards, and push the plastic cap (14) home firmly. -
Page 8: Maintenance
Filler Cap (shown in fig 7). Attached to the filler cap is a dipstick; the oil level should be within the notch on the stem. Top up with Clarke Hydraulic oil if necessary. 3. Every 400 hours of use. -
Page 9: Sharpening The Blade
WARNING: NEVER MIX OIL WITH GENERAL WASTE. USED OIL MUST BE DISPOSED OF ACCORDING TO CURRENT REGULATIONS. Sharpening the Blade After long periods of operation, and when required, sharpen the cutting edge of the blade, using a file or portable grinder, to a fine point. How to free a jammed log Fig.10 Release both controls: the log pusher will be... -
Page 11: Spare Parts List
SPARE PARTS LIST No. Description Qty Part No. No. Description Qty Part No. 1 Lever Locknut 1 BLB41000480 48 Valve Spring 1 BLB51050250 2 Valve Lever 1 BLD05411230 49 Valve Seat 1 BLB72150070 3 Lever Guard 1 BLB62200070 50 O-Ring Seal 2 BLE25830043 4 Alu Washer 5 BLE51432014...
