FOOT OPERATED 1.5 TONNE LOG SPLITTER
MODEL NO: LOGBUSTER 10
PART NO: 3402046
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0815

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOGBUSTER 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke LOGBUSTER 10

  • Page 1 FOOT OPERATED 1.5 TONNE LOG SPLITTER MODEL NO: LOGBUSTER 10 PART NO: 3402046 OPERATION & MAINTENANCE INSTRUCTIONS LS0815...
  • Page 2: Specifications

    INTRODUCTION Thank you for purchasing this CLARKE Foot Operated 1.5 Tonne Log Splitter. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: Safety Symbols

    SAFETY SYMBOLS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 4: General Safety Rules

    GENERAL SAFETY RULES WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY. WARNING: SAVE THESE INSTRUCTIONS. WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2.
  • Page 5: Additional Precautions For Log Splitters

    SERVICE 1. Have your log splitter serviced by a qualified repair person using only identical replacement parts. This will ensure that safety is maintained. ADDITIONAL PRECAUTIONS FOR LOG SPLITTERS • All personnel must read the manual or receive correct training before they use the log splitter.
  • Page 6: Before Use

    BEFORE USE SETUP 1. Place the log splitter on flat, level ground and swing the stand into position. • Make sure that the log splitter is stable. PREPARING THE LOGS 1. Cut the logs to between 100-400 mm long to fit into the log splitter. the logs must not exceed 200 mm in diameter.
  • Page 7: Operating The Log Buster

    OPERATING THE LOG BUSTER Before use, make sure that all nuts and bolts are tight and that the tool is in good condition before using it. CAUTION: DO NOT PUT YOUR HANDS ANYWHERE NEAR THE SPLITTING WEDGE DURING USE. CAUTION: KEEP YOUR HANDS AWAY FROM SPLITS AND CRACKS WHICH OPEN IN THE LOG;...
  • Page 8: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE REMEDY Fails to split logs Log is improperly positioned. Reposition the log See “Preparing the logs” on page 6. Wedge cutting edge is blunt. Refer to “Sharpening The Wedge” below. MAINTENANCE WARNING: MAKE SURE THAT THE RAM ON THE LOGBUSTER IS NOT UNDER PRESSURE WHEN YOU ARE CLEANING, MOVING OR MAKING ANY ADJUSTMENTS.
  • Page 9: Exploded Diagram

    EXPLODED DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 10: Parts List

    PARTS LIST DESCRIPTION PART NO Slidestop QMLOGB1001 Log Guide Plate QMLOGB1002 Spacer Bush QMLOGB1003 M8 Lock Nut QMLOGB1004 M8 Nut QMLOGB1005 Spring Gasket QMLOGB1006 Hexagonal Bolt QMLOGB1007 Support Beam QMLOGB1008 Wheel QMLOGB1009 Circlip QMLOGB1010 M8x40 Screw Ring QMLOGB1011 M8x50 Hexagonal Bolt QMLOGB1012 Clamp Axis QMLOGB1013...
