Page 1: Log Splitter
LOG SPLITTER MODEL NO: LOGBUSTER 6 PART NO: 3402035 OPERATION & MAINTENANCE INSTRUCTIONS 10/08... -
Page 2: Introduction
INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Table Of Contents
CONTENTS Introduction ................2 Guarantee .................. 2 In the box ..................2 Contents..................3 General safety rules ..............4 Additional safety rules for log splitters ........5 Safety symbols ................7 Electrical connections ............... 8 Identification of parts ..............9 Assembly .................. -
Page 4: General Safety Rules
GENERAL SAFETY RULES WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. SAVE THESE INSTRUCTIONS. WORK AREA Keep the work area clean and well lit. Cluttered and dark areas invite accidents. Do not operate log splitters in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. -
Page 5: Additional Safety Rules For Log Splitters
USAGE AND CARE Do not force the log splitter. It will do the job better and safer at the rate for which it was designed. Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the log splitter. Such preventive safety measures reduce the risk of starting the log splitter accidentally. - Page 6 12. Never use the log splitter if it is damaged or if it needs servicing. 13. Before starting work, check correct functioning of all the safety devices and check for soundness of welded joints, securing nuts & bolts. SIZE OF THE LOGS BEING SPLIT The image on the right shows the maximum log size that can be split.
-
Page 7: Safety Symbols
SAFETY SYMBOLS... -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &... -
Page 9: Identification Of Parts
IDENTIFICATION OF PARTS Description Part number No Description Part number Ram travel adjusting LGLOGB601 Oil tank cover / air LGLOGB610 bleeder Transport handle LGLOGB602 Wheels LGLOGB611 Split wedge LGLOGB603 Base LGLOGB612 Control levers LGLOGB604 Star knob LGLOGB613 connection bracket Top motor shield LGLOGB605 Side bracket for LGLOGB614... -
Page 10: Assembly
ASSEMBLY FITTING THE CONTROL ARMS 1. Position the control lever into the side of the arm assembly as shown. • Make sure the control lever goes into the slot on the arm assembly. 2. Lock the arm assembly in to position with the bolt, large washer, small washer and nut supplied. - Page 11 FITTING THE SUPPORT TABLE There are 3 positions available for the support table to accomodate different log lengths. 1. Insert the support table arms into both side brackets. 2. Insert the star knob to lock the support table into position. •...
-
Page 12: Operation
OPERATION PREPARATION • Plan your work before hand. Have your logs positioned where they can be easily reached. • Route the cord from the power source to the splitter in a way that safeguards against tripping on the cord, or the cord becoming damaged during the work session. - Page 13 INSERT THE MAINS LEAD 1. Insert the adapter plug into the socket shown on the right. 2. Insert the mains plug into the mains power supply and switch TURNING THE LOG SPLITTER ON/OFF While operating under extremely low temperature, turn on the log splitter on 15 minutes before use to preheat the hydraulic oil.
- Page 14 SPLITTING A LOG This log splitter is designed to be operated by one person only and requires two handed operation by the user - CAUTION: SPLIT LOGS IN THE DIRECTION OF THE GRAIN. DO NOT PLACE LOGS ACROSS THE LOG SPLITTER FOR SPLITTING. IT MAY BE DANGEROUS AND MAY SERIOUSLY DAMAGE THE MACHINE.
- Page 15 ADJUSTMENTS TO SET WEDGE RAM STROKE Adjusting the ram stroke will set the height which the ram will return to, when you release the control levers. 1. Press down on both control levers until the splitting wedge is at the desired height.
-
Page 16: Maintenance
2. Using a clean funnel, pour in CLARKE hydraulic oil until the oil level is 2-3 cm from the top of the oil tank. IMPORTANT: Only use CLARKE HYDRAULIC OIL, available from your nearest dealer. Part No: 1Ltr - 3050830 5Ltr - 3050835 3. -
Page 17: Troubleshooting
Extension lead is defective Unplug, check and replace if necessary Switch is defective Return the unit to your local Clarke dealer for servicing. Log splitter does not Air bleeder is not open Open oil bleeder. work while the Control levers are bent Repair the bent control motor is running. -
Page 18: Specifications
320 mm PARTS AND SERVICING For Parts & Servicing, please contact your nearest dealer, or CLARKE International, on one of the following numbers PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 or e-mail as follows: PARTS: Parts@clarkeinternational.com... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY...
