- Page 1 10 Ton LOG SPLITTER 10 Ton LOG SPLITTER MODEL NO: Log Buster 4 PART No: 3402025 OPERATION & MAINTENANCE INSTRUCTIONS 0308...
-
Page 2: Specifications
Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. When disposing of this product, do not dispose of with general waste. It must be disposed of according to the laws... -
Page 3: Safety Precautions
Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. ALWAYS Learn the machines applications, limitations and the specific potential hazards peculiar to it. -
Page 4: Additional Precautions For Log Splitters
Additional Precautions for Log Splitters Extra special care is required when using this powerful tool to safeguard yourself and others around you. • Before using the log splitter, check for fluid leaks. Be sure the tool and the work area around it is clean and free of oil spills. -
Page 5: Operation
Assembly The Logbuster-4 is fully assembled except for the transportation wheels. Position the wheels and washers (supplied) into position, insert the axle pin from the outside and secure with the split pin provided, in the manner shown in Fig.2 NOTE: The logsplitter may be lifted at the splitting wedge end, using the brace, shown in Fig.3, which will raise the pump end on to its wheels, allowing the unit to be transported to a suitable position. -
Page 6: Maintenance
4. Check the oil level which should be approx. 1/4” below the filler neck. If necessary, top up with CLARKE hydraulic oil, available from your CLARKE dealer. 5. Finally, carefully replace the filler plug using a small implement to ensure the securing lip is prodded into place inside the filler hole. -
Page 7: Troubleshooting
Fit new oil seals, consult your Oil leaks. nearest CLARKE dealer. IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, decreased tool performance and may invalidate your warranty. PARTS & SERVICE TEL: 020 8988 7400 e-mail as follows: PARTS: Parts@clarkeinternational.com... -
Page 8: Parts Diagram
Parts Diagram Parts List Item Description Part No Frame N023-10000-000 Clevis pin wrap N020-20004-000 Jacks Top Plate N020-20000-000 clevis N020-20003-000 Jacks N020-30000-000 Spring N020-00002-000 Operating Lever N020-40000-000 U-Clamp N020-00001-000 Bolt 9103-10025-000 Spring Washer 9303-10000-000 Washer 9703-10000-000 Split Pin 9404-03025-000 Shaft N020-00004-000 Wheel N020-00005-000...
