MiDi CONTROL

The Programmable EQ features a MIDI input that can be used to remotely
engage and bypass the unit as well as selecting presets. It also allows for
potential future firmware updates for feature changes or future interfac-
ing with a software editor.
MIDI Implementation Table:
Parameter
Enable Preset 1
Enable Preset 2
Enable Preset 3
Enable Preset 4
Disable Preset – Bypass
Parameter
Output
Engage/Bypass
The MIDI Channel is accessible as a Backpage parameter. See the next
section for details
6 | MIDI Control
Message Type
Program Change
Program Change
Program Change
Program Change
Program Change
Message Type
Continuous Controller
Continuous Controller
Data Value
001
002
003
004
005
Data Value 1
Data Value2
030
031
<64 Bypass
>=64 Engage
0–127
