C O N N E C T I N G - A N T E N N A

CON NE C T I N G C M - 7 0 0 0 T O A T V U SI N G RF C O A X IAL C A BL E
Terrestrial Antenna
(outdoor or indoor)
Back of CM-7000
G O O D
C ON N EC TI N G C M - 7 0 0 0 T O A V C R U S I N G RF C O A X IAL C AB L E
Terrestrial Antenna
(outdoor or indoor)
Back of CM-7000
G O O D
CM-7000 D2A DIGITAL TO ANALOG CONVERTER
RF Coaxial Cable
RF Coaxial Cable
F I G U R E 1
CVBS L R ANT IN
Back of TV
F I G U R E 2
CVBS L R ANT IN
Back of TV
RF Coaxial Cable
OUT
IN
Back of VCR
5
