CM-7000 D2A DIGITAL TO ANALOG CONVERTER
C O N N E C T I N G - A N T E N N A
CON NE C T I N G C M - 7 0 0 0 T O A T V U SI N G RC A C A B LE
Terrestrial Antenna
(outdoor or indoor)
Back of CM-7000
B E T T E R
CON NE C T I N G C M - 7 0 0 0 T O A T V U SI N G RC A & S- VIDEO C AB L E
Terrestrial Antenna
(outdoor or indoor)
Back of CM-7000
B E S T
6
RCA Audio/Video Cable
Audio RCA Cable
S-Video Cable
F I G U R E 3
CVBS L R ANT IN
Back of TV
F I G U R E 4
CVBS L R ANT IN
Back of TV
