I N T R O D U C T I O N

The Channel Master by PCT CM-7000 is a high quality
HD/SD (high definition/standard definition) digital ATSC
to analog NTSC television converter box. Using the CM-
7000 for direct terrestrial FTA HD reception allows users
to view HD programs on SD TV sets.
The combination of a CM-7000 Digital Analog Converter
with a Channel Master digital antenna is a perfect
solution for terrestrial reception in a very wide range of
reception conditions and landscape relief.
F E A T U R E S
• Converts all digital video formats,
including HD (High Definition) into
SD (standard definition)
analog format
• Easy installation and operation
• Automatic and manual programming
• Electronic Program Guide (EPG) support
• On Screen Display (OSD)
• Closed Caption (CC)
• Full function remote control
• Low power consumption
• Auto-Sleep function

S A F E T Y !

POWER Power this box only from a power source within the specified voltage range
To prevent electrical shock, be sure the electrical plug used on the box's power cord matches
the electrical outlet in use.
Do not open the top cover when the box is plugged into an electrical outlet.
CONNECTION Connect all peripheral devices before plugging the power cord into the electrical outlet.
Unplug power cord from the electrical outlet before disconnecting any peripheral devices.
GROUNDING Terrestrial antenna must be grounded to provide protection from lightning and build-up of
static electricity.
LIGHTNING For protection from lightning or when the box is left unattended for a long period, disconnect
it from the power source.
VENTILATION The slots on the top of the CM-7000 must be left uncovered to allow proper airflow to the unit.
Do not cover the top with fabric, paper, or other materials.
Do not stack electronic equipment on top of the CM-7000.
OVERHEATING Do not install this box on soft furnishings or carpet.
Do not expose this box to direct sunlight or place it near a heater.
Do not install this box in small or non-ventilated openings between furniture.
LIQUIDS This box should not be exposed to liquids nor should objects filled with liquid be placed on
top of the box.
ENVIRONMENT CM-7000 is for indoor use only under specified conditions.
CLEANING Disconnect the box from the electrical outlet before cleaning.
Use a light damp cloth (no solvents) to clean the box.
CM-7000 D2A DIGITAL TO ANALOG CONVERTER
For energy saving, which is in compliance with NTIA
recommendations, the Auto-Sleep Function activates
Standby mode four (4) hours after last user entry from
the remote control, but not before the end of a currently
viewed event.
On/Off
Power LED
Light*
* Green = ON, Orange = Stand-By, Red = Booting Up
Note: Initial boot up process occurs when the unit is
first plugged in. Boot up may take up to 45 seconds
to complete and is followed by a green LED.
Channel Channel IR Remote Window
Down Up
Not a display window
3
