CM-7000 D2A DIGITAL TO ANALOG CONVERTER
C O N N E C T I N G
C O N N E C T I N G C M - 7 0 0 0 T O A T V U S I N G R C A C A B L E
Terrestrial Antenna
(outdoor or indoor)
CVBS L R
ANT IN
CM-7000
TV
RCA Cable
C O N N E C T I N G C M - 7 0 0 0 T O A T V U S I N G R F C O A X I A L C A B L E
Terrestrial Antenna
(outdoor or indoor)
CVBS L R
ANT IN
CM-7000
TV
RF Coaxial Cable
4
