4 | DIVAR AN 3000
Connectors
Video inputs
4, 8 or 16 BNC
Monitor outputs
1 VGA D-SUB
1 HDMI
2 channel BNC (CVBS)
Alarm inputs
16 screw terminal inputs, cable diameter
AWG26‑16 (0.13–1.5 mm)
Alarm outputs
3 screw terminal outputs, cable diameter
AWG26‑16 (0.13–1.5 mm)
Audio inputs
4 RCA
Audio outputs
1 RCA
Audio bidirectional
1 RCA for talk input or output
(MIC)
Ethernet
RJ45, 10/100/1000Base-T according to
IEEE802.3
RS485
Screw terminal output
RS232
DB9 male, 9-pin D-type
USB 2.0
One front and one rear USB connector for
mouse or USB memory device
+12 VDC
External power input

Video recording

Recording
Speed
Max. 30 IPS per channel (NTSC),
configurable
Max. 25 IPS per channel (PAL), configurable
Mode
Manual, motion detection, scheduled, alarm
Network control
View alarm
External, motion detection, system alarms
and video loss
Audio
Bidirectional (audio input and output
connected via device)
PC software
Bosch Video Client
Playback
Multi-channel
Simultaneous 1/4/9/16 channels
Mode
Frame-by-frame, slow play, fast play,
reverse
Search
Time, channel, type, smart
Network
Bosch Video Client or Web Client software
Alarm Handling
Motion detection
Detection zones: 396 (PAL) / 330 (NTSC)
Video loss
External alarm and screen prompt
Storage
Internal
2 SATA HDD or 1 HDD + 1 DVD (R/RW)
Max. capacity per HDD: 3 TB
Max. supported speed per HDD: 6 Gb/s
Exporting
DVD (optional)
Built-in DVD+R/RW writer
USB
Flash memory or external HDD (FAT32)
Network
Bosch Video Client or Web Client software
Mechanical
Dimensions (WxDxH)
375 x 290 x 50 mm (14.8 x 11.4 x 2.0 in)
excluding cabling and feet (5 mm)
Weight
2.5 kg (5.51 lb) approx.
excluding HDD(s) and DVD writer
Environmental
Temperature (incl. HDD(s) and DVD writer)
Operating
+0°C to +40°C (+32°F to +104°F)
Storage
-40°C to +70°C (-40°F to +158°F)
Humidity
Operating
<93% non-condensing
Storage
<95% non-condensing

Ordering information

DIVAR AN 3000
960H/RT digital recorder for analog camera video
management. HDMI/VGA/CVBS outputs; audio; H.264;
PTZ control; web interface; free viewing Apps;
4 channels; base unit
Order number
DVR-3000-04A000
DIVAR AN 3000
960H/RT digital recorder for analog camera video
management. HDMI/VGA/CVBS outputs; audio; H.264;
PTZ control; web interface; free viewing Apps;
8 channels; base unit
Order number
DVR-3000-08A000
DIVAR AN 3000
960H/RT digital recorder for analog camera video
management. HDMI/VGA/CVBS outputs; audio; H.264;
PTZ control; web interface; free viewing Apps;
16 channels; base unit
Order number
DVR-3000-16A000
DIVAR AN 3000
960H/RT digital recorder for analog camera video
management. HDMI/VGA/CVBS outputs; audio; H.264;
PTZ control; web interface; free viewing Apps;
4 channels; DVD
Order number
DVR-3000-04A001
