3 | DIVAR AN 3000
3 Audio inputs
4 Audio output
5 Alarm inputs
6 RS232 connector for Dome
control
7 Power ON/OFF switch
8 Power connector
Recommended PC requirements for Web support
Operating system
Windows XP, Windows Vista or Windows 7
Web browser
Safari, Chrome, Firefox (QuickTime required;
no playback supported)
Internet Explorer 9 (including playback)
Processor
Intel Core Duo 2.0 GHz or comparable
RAM memory
2048 MB
Free disk space
10 MB
Graphics card
NVIDIA GeForce 8600 or better
Video memory
256 MB
Network interface
10/100/1000-BaseT

Technical specifications

Electrical
Rated voltage and power
External power adapter
100–240 VAC; 50-60 Hz; 1.7 A
AC input
Power adapter DC
12 VDC; 5 A
output
DVR Power input
12 VDC; 35 W, 119 BTU/h
RTC battery on main
Lithium CR2032, 3 VDC
PCB
Video
Video standard
PAL or NTSC (select via General Setup
menu, or auto detect on channel 1)
960H resolution support
Playback
960H: 960x576 (PAL), 960x480 (NTSC)
4CIF: 704x576 (PAL), 704x480 (NTSC)
2CIF: 704x288 (PAL), 704x240 (NTSC)
CIF: 352x288 (PAL), 352x240 (NTSC)
QCIF: 176x144 (PAL), 176x120 (NTSC)
Compression
H.264
Inputs
4, 8 or 16 composite video 1 Vpp, 75 ohm,
CVBS (BNC)
Outputs
1 channel Mon. A: CVBS (BNC)
1 channel Mon. A: HDMI
1 channel Mon. A: VGA
1 channel Mon. B: CVBS (BNC)
11 HDMI output - Monitor A
12 USB connector
13 RS485 connector for Dome
control
14 Alarm outputs
15 Microphone input
16 CVBS output - Monitor B
Support for simultaneous CVBS/VGA/HDMI
output to Mon. A
Monitors
MON.A
Live, playback, menus
VGA: analog RGB max. 1920x1080, 60 Hz
HDMI: digital RGB max. 1920x1080,
165 MHz
CVBS: 1 Vpp, 75 ohm, BNC (NTSC/PAL)
Resolution (MON.A)
CVBS (PAL): 704x576
CVBS (NTSC): 704x480
VGA: 1920x1080, 1280x1024,
1280x720, 1024x768
HDMI: 1920x1080, 1280x1024,
1280x720, 1024x768
960H camera: 960x576 (PAL),
960x480 (NTSC)
720H camera: 704x576 (PAL),
704x480 (NTSC)
MON.B
Live
CVBS: 1 Vpp, 75 ohm, BNC
Resolution (MON.B)
CVBS (PAL): 704x576
CVBS (NTSC): 704x480
Audio
Inputs
4-ch RCA (for 4/8/16 channel), 200 to
3000 mV, 10 kOhm (RCA)
Output
Mono RCA, 200 to 3000 mV, 5 kOhm (RCA)
MIC input
Mono talk input RCA, 200 to 3000 mV,
10 kOhm (RCA)
Compression
G.711A
Sample rate
8 kHz per channel
Bit rate
8-bit
Control
RS485
PTZ control port
Output signals according to RS485, max.
signal voltage -5 to +5 V
RS232
PTZ control port interface
Output signals according to EIA/TIA-232-F,
max input voltage ±10 V
Supported protocols
Pelco P and D (over RS-485)
Bosch OSRD (over RS-485 or RS-232)
Alarms
Inputs
16 inputs configurable NO/NC, max. input
voltage 5 VDC
Outputs
3 relay outputs, configurable NO/NC
Relay contact
Max. rated, 30 VDC, 2 A continuous or
125 VAC, 1 A (activated)
