Thread Sensor 2:6 - Pfaff Creative Performance Owner's Manual

Threading for twin needle
Replace the sewing needle with a twin needle. Make
sure that the presser foot is raised and the needle is
in the up position.
1. Place the thread on the spool pin and t a spool
cap of the right size. Raise the auxiliary spool
pin. Slide on a large spool cap and a felt pad.
Place the second thread on the spool pin.
Note: Hold threads with both hands to prevent them from
slacking while threading. This ensures that the threads
will be positioned properly in the threading path.
2. Pull the threads into the thread guide by pulling
them from the front to the back (A). Make
sure the threads click into place. Then pull the
threads underneath the bobbin winder thread
guide (B) on the pre-tension disc (C).
3. Thread down through the right-hand threading
slot and then upwards through the left-hand
threading slot. Make sure that you pass one
thread to the left and one thread to the right
sides of the tension disk (F).
4. Bring the threads from the right into the take-up
lever (D) and down in the left-hand threading
slot. Make sure that one thread is inside the
needle thread guide (E) and the other one
outside. Make sure that the threads do not
become twisted together.
5. Thread the needles.
Note: Activate twin needle and select the correct twin
needle width in Settings menu. This will limit the width
of all stitches for that needle size to prevent damage to
presser foot and needle.
Thread sensor
If the upper thread breaks or bobbin thread runs
out, the machine stops and a pop-up appears on the
screen.
If upper thread breaks: Re-thread the machine and
touch OK on the pop-up. If bob bin thread runs out:
replace with a wound bobbin and continue sewing.
2:6
B
C
F
D
E
B
C
A
A
