Section 3 - Configuration

Enter the destination network address, subnet mask, gateway

AND/OR available WAN interface then click "Apply" to add the

entry to the routing table.

If Enable Automatic Assigned Default Gateway checkbox is

selected, this router will accept the first received default gateway

assignment from one of the PPPoA, PPPoE or MER/DHCP

enabled PVC(s). If the checkbox is not selected, enter the static

default gateway AND/OR a WAN interface. Click "Apply" button

to save it.

To activate RIP for the device, select the 'Enabled' radio button

for Global RIP Mode. To configure an individual interface, select

the desired RIP version and operation, followed by placing a

check in the 'Enabled' checkbox for the interface. Click the 'Apply'

button to save the configuration, and to start or stop RIP based

on the Global RIP mode selected.
