Quick Installation Guide

Check Your Package Contents
DVG-N5412SP
VoIP Router
Antenna X 2
DVG-N5412SP
VoIP Wireless Router
X 2
Phone Cord
Stand
Ether Cable
(CAT5 UTP)
CD-ROM
12VDC, 2A
Power Adapter
Using a
power adapter
with a different
voltage rating will
damage this
product and void
the warranty.

Advertisement

Table of Contents
loading

Related Manuals for D-Link DVG-N5412SP

Summary of Contents for D-Link DVG-N5412SP

  • Page 1: Quick Installation Guide

    Quick Installation Guide DVG-N5412SP VoIP Wireless Router Check Your Package Contents DVG-N5412SP Ether Cable 12VDC, 2A Phone Cord VoIP Router (CAT5 UTP) Power Adapter Using a power adapter with a different voltage rating will damage this product and void the warranty.

  • Page 2: Front Panel

    Prov./Alm：A blinking light indicates the DVG-N5412SP can not register with SIP Server or can not get the IP address. A blinking light also indicates the DVG-N5412SP is attempting to connect with the Provisioning server. Once the service connects, the LED will turn off.

  • Page 3: Rear Panel

    Ground: A conducting connection with the earth. Connect with the ground so as to make the earth a part of an electrical circuit using metal wire. Power Receptor: Receptor for the provided power adapter. Power Switch: Press down to turn-on DVG-N5412SP.

  • Page 4: Installing The Hardware

    Installing the Hardware A. Insert one end of the Ethernet cable into the Ethernet (LAN) port on the back panel of the DVG-N5412SP and the other end of the cable to an Ethernet Adapter or available Ethernet port on your computer.
  • Page 5 E. Connect the power adapter to the power input at the back panel of the DVG-N5412SP and then plug the other end of the power adapter to a wall outlet or power strip then press power switch. On the front of the device, the Power LED will turn On to indicate proper operation.
  • Page 6 Installing the Hardware (continued) After the installations are completed, your network should look similar to the diagram below. DVG-N5412SP Hardware configuration is complete! If your VoIP service is already activated, you can make phone calls now.
  • Page 7 Configuration To access the web-based configuration utility, open a web browser such as Internet Explorer and enter the IP address of the DVG-N5412SP. Open your Web browser and type http://192.168.8.254 into the URL address box. Press the Enter or Return Key.
  • Page 8 Configuration (continued) Click Next. The username of ADMIN and USER have been defined and locked by default. It is highly recommended to create a login password to keep your router secure. Click Next. Enter a NTP server or use the default server.
  • Page 9 Configuration (continued) Select your Internet connection type: DHCP – Most Cable ISPs or if you are connecting the DVG-N5412SP behind a router. Static IP – Select if your ISP supplied you with your IP settings. PPPoE – Most DSL ISPs.
  • Page 10 Click Next. Select your wireless security modes for your wireless network. Click Next Setup is finished. Check the summary of your settings. To make new settings effective, you must click on the Restart button to reboot the DVG-N5412SP. Click Restart.

  • Page 11: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within United States: D-Link Technical Support over the Telephone: (800)326-1688 D-Link Technical Support over the Internet: http://support.dlink.com email:support@dlink.com...
