CHIEF FCAB3X1U Installation Instructions Manual

Menu board back row add-on kits

Advertisement

Quick Links

I N S T A L L A T I O N I N S T R U C T I O N S
FCAB3X1U
(shown attached to LCM3X1U)
FCAB3X1UP
Menu Board Back Row Add-On Kits
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCAB3X1U / FCAB3X1UP

Advertisement

loading
Need help?

Need help?

Do you have a question about the FCAB3X1U and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF FCAB3X1U

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S FCAB3X1U (shown attached to LCM3X1U) FCAB3X1UP Menu Board Back Row Add-On Kits Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCAB3X1U / FCAB3X1UP...
  • Page 2: Important Safety Instructions

    (56.7 kg) 750 lbs (340.2 kg) no responsibility for accuracy, completeness or sufficiency of the information contained in this document. Chief® is a registered trademark of Milestone AV Technologies. All rights reserved. WARNING: Never operate this mounting system if it is damaged.
  • Page 3 Installation Instructions FCAB3X1U / FCAB3X1UP DIMENSIONS FCAB3X1U 108.00 2743.2 DIMENSIONS: INCHES [MILLIMETERS] FCAB3X1U TILT RANGE -5° TO +20° 16.75 425.5 DIMENSIONS: INCHES [MILLIMETERS]...
  • Page 4 FCAB3X1U / FCAB3X1UP Installation Instructions DIMENSIONS (cont’d) FCAB3X1U [400mm Mounting Pattern] 15.75 400.0 DIMENSIONS: INCHES [MILLIMETERS] FCAB3X1U [600mm/800mm Mounting Patterns] 23.62 600.0 DIMENSIONS: INCHES [MILLIMETERS]...
  • Page 5 Installation Instructions FCAB3X1U / FCAB3X1UP DIMENSIONS (cont’d) FCAB3X1UP 68.00 1727.2 DIMENSIONS: INCHES [MILLIMETERS] FCAB3X1UP FCAB3X1U 7.02 178.3 DIMENSIONS: INCHES [MILLIMETERS] LCB2X1UP...
  • Page 6 FCAB3X1U / FCAB3X1UP Installation Instructions DIMENSIONS (cont’d) FCAB3X1UP 2.04 51.7 TILT RANGE -5° TO +20° DIMENSIONS: INCHES [MILLIMETERS] FCAB3X1UP [400mm Mounting Pattern] 15.75 DIMENSIONS: INCHES 400.0 [MILLIMETERS]...
  • Page 7: Installation Instructions

    Installation Instructions FCAB3X1U / FCAB3X1UP LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon...
  • Page 8: Tools Required For Installation

    FCAB3X1U / FCAB3X1UP Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8" (included) 3/16" (included) 1/2" or 13mm M5 (included) 3/8" PARTS [Interface Bracket Hardware Kit] (3 bags total - quantities listed per bag) S (2) A (8) B (6) C (6)
  • Page 9 Installation Instructions FCAB3X1U / FCAB3X1UP INSTALLATION Slide top T-slot studs (DD) with attached lock nuts (AA) down into top openings on add-on heads (S). (See Figure 3) The following installation instructions assume that the UL Listed Slide studs on lower T-slot studs (DD) into lower slots on...
  • Page 10 FCAB3X1U / FCAB3X1UP Installation Instructions Attaching Interface Brackets to Display Attaching Displays to Ceiling Mount Lower the latch mechanism on all interface brackets (EE). (See Figure 5) WARNING: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The weight of the displays must be evenly distributed as the displays are added to the ceiling mount.
  • Page 11 Installation Instructions FCAB3X1U / FCAB3X1UP Fasten bracket against ceiling mount extrusion using one Tilt 10-24 x 5/8" button head cap screw (T). (See Figure 9) The interface brackets allow -5° to 20° tilt, and can be locked at 0°, 10° and 20° tilt.
  • Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...

This manual is also suitable for:

Fcab3x1up
