The DL5200 lock provides three "security levels": Master (can perform ALL functions), Manager (can perform SOME program-
ming functions plus entry), and Basic User (entry only). In total, there are 104 "locations" inside the DL5200 lock: one Master
Code, 10 Manager and 90 User Access Codes, and three "one-time entry" Service Codes. Where the Access Code is located
will determine its security level. From the factory, all locations (except for the Master Code) are empty; each location can then be
programmed to contain an Access Code, and these Access Codes enable Users to program and/or unlock the lock. As a visual
aid, the 100 Manager/User Access Code locations are detailed in the grid below, with ten "Banks" (columns) of ten "Managers/
Users" (rows). Each of the 100 squares in the grid is identified by a unique two-digit location (00) through (99). Notice that these
two digits also specify its Bank (column) and Manager/User (row) location in the grid. Also notice that all Managers are in the top
row, their locations all ending in a zero (locations 00, 10, 20, 30 and so on through 90). Note: Use the blank grid below as a Pro-
gramming Worksheet for preparing all programming in advance. Store this worksheet in a safe place for future reference.
Each square represents a location inside the lock (excluding the Master Code and the 3 Service
