Operation: 401X Quad Receiver - Nady Systems 401x QUAD Owner's Manual

401x QUAD Receiver
1. Powering the Receiver
Plug the 16V
AC/DC ADAPTER (1)
Then plug the power supply into an AC outlet. [Note: Any 16V DC source with 800mA capability
can also be used.]
Turn
VOLUME CONTROL (6)
of the receiver. Once the receiver is connected to a power source, press the
ON position. The
POWER ON LED (4)
The
TX LED INDICATOR (7)
four channels is receiving a signal from your system's transmitter.
2. Antennas
The assembly consists of two antennas. Connect antennas into the
ANTENNAS (2)
on the front of the receiver. Extend the antennas fully to obtain maximum range.
JACKS (5)
Position
ANTENNAS (2)
range, it is always best to maintain a line of sight (no obstructions) between the receiver antennas
and the transmitter whenever possible.
3. Mute (Squelch) Adjustment
In normal operation, the
minimum RF level of 1μV for maximum sensitivity. Doing so sets each receiver for maximum range.
However, in areas of high RF activity, the mute (or squelch, as it is sometimes called) may need to
be adjusted to compensate for the adverse conditions in a particular location. If, with the transmitter
off, its corresponding LED on the receiver front panel flickers or stays on, the
should be turned clockwise until the LED extinguishes. For each of the four channels, when the
Mute is properly adjusted, the corresponding LED will light only when the system's transmitter is
turned on. Turning the
quieter signal during dropouts or at the end of the operating distance range.
4. Connecting the Audio Output
The output stage of each channel and the separate four channels mixed output of the 401X QUAD
are all configured for adjustable unbalanced LINE and fixed balanced XLR line or microphone audio
outputs. The adjustable unbalanced ¼" mix out is a low level LINE with an output impedance of
600 ohms. The individual fixed level balanced XLR out can be configured as high level line out with
11k ohms output impedance or microphone level out with a 600 ohms load impedance.
For each channel you wish to use, insert an audio cord with a balanced female XLR plug into its
jack on back of the receiver. Plug the other end of each cord into your amplifier, effect
AF OUTPUT (10)
or mixing board. Adjust volume on your mixing board so that no audio distortion in present when
amp or mixer is set at its usual level. [Note: To prevent possible undesired noises during use, leave
the volume controls of unused channels (with the corresponding transmitter off) turned off in the
amp or mixer. The audio should only be "live" if the transmitter is on.]
If you want to use the 401X QUAD as it own mixer (your amplifier, effect or mixing board should
have 12dB or more gain select on), you can connect to the
mixed line output of up to all four channels, with the relative volume of each channel in the mix
determined by that channel's
opeRaTIon
provided into the
for all four channels counterclockwise to mimimum located on the front
indicator will light up.
on the front panel of the receiver will not light up until one or more of the
at 45 degrees from the horizontal; 90 degrees from each other. For maximum
MUTE CONTROL (9)
too far clockwise will result in reduced range, but yield a
MUTE CONTROL (9)
VOLUME CONTROL (6)
DC INPUT JACK (11)
should be set fully counterclockwise to the factory preset
MIX AF OUTPUT (8)
.
3
on the back of the receiver.
POWER SWITCH (3)
ANTENNA
MUTE CONTROL (9)
which provides a
to
