Rear Panel Connectors - Mach P4MST-890 Setup Manual

S/PDIF o ut co nnector
CPU Fan hea der
System Fan hea der
Clear CMOS header
USB connector
Power Connector ( 24pi n)
Power Connector ( 4pin)
PS/2 Keyboard
PS/2 Mo use
Serial Port
Printer Port
Back Panel
VGA Port
I/O
LAN port
USB Port
Audio J ack
Board Size 190 mm (W) x 244 mm (L)
OS
Windows 2000 / XP
Support
1.4 R P
EAR ANEL
PS/2
Printer Port
Mouse
PS/2
COM1
Keyboard
SPEC
x1 Supports di gital a udio out function
CPU Fan power s upply (with Smart Fa n
x1
function)
x1 System Fan Power supply
x1 Restore CMOS data to factory defa ult
Each connector supports 2 fr ont panel USB
x2
ports
x1 Connects to Power supply
x1 Connects to Power supply
x1 Connects to PS/ 2 Key board
x1 Connects to PS/ 2 Mo use
x1 Provide RS- 232 Serial connection
x1 Connects to vari ous types of device
x1 Connects to mo nitor.
x1 Connects to RJ- 45 ether net cable
x4 Connects to USB devices
x3 Provide A udio-I n/Out a nd micropho ne
connection
Micro ATX form Factor
Biostar Reserves the right to a dd or r emove
support for any OS with or witho ut notice.
C
ONNECT ORS
USBX2
VGA
P4MST-890
LAN
Li ne In/
Surround
Line Out
Mic In 1/
Bass/ Center
USBX2
5
