1.3 M
OT HERBOARD
LGA 775
Intel Core 2Duo/ Pe ntium 4 / Pe ntium D /
CPU Celeron D pr ocessor up to 3.8 GHz
*It is recommende d to use processors
with 95W power consumption.
FSB 533 / 800 / 1066 MHz
VIA P4M890
Chipset
VIA VT8237A
Graphic Integrated i n U niChrome Pro Chipset
ITE IT8712F
Provides the most commonly used
Super I/O
legacy Super I/O functionality.
Low Pin C ount Interface
DIMM Slots x 2
Supports DDR2 533
Main
Each DIMM supports
Memory
256/512MB/1GB/2GB DDR2
Max Memory C apicity 4GB
IDE Integrated I DE Controller
SATA Integrated Seri al ATA Controller
LAN PHY Realtek RTL 8201CL PH Y
Sound
ALC861VD
Codec
PCI Expr ess x 16 slot
Slots PCI Expr ess x 1 slot
PCI slot
On Board Floppy connector
Connector IDE Co nnector
SATA Connector
Front Pa nel Co nnector
Front Audi o Co nnector
CD-in Co nnector
4
F
EAT URES
SPEC
Supports Hy per Tra nsport/ Execute Disable
Bit/ Enhanced Intel S peedStep®/ Intel
Extende d Memor y 64 technolo gy
Max Share d Vide o Memory is 64 MB
Enviro nment Co ntrol initiatives,
H/W Monitor
Fan Spee d Co ntroller
ITE's "Smart Guardia n" function
Single Channel Mode DDR2 memory mo dule
Registered DIMM and ECC DIMM is not
supported
Ultra DMA 33~133 B us Master Mode
supports PIO Mo de 0~4,
Data transfer rates up to 1.5 Gb/s.
SATA Version 1.0 specification complia nt.
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
5.1 cha nnels a udio o ut
High- Defi nition Audio s upport
x1 Supports PCI express x 16 expansion cards
x1 Supports PCI express x 1 e xpa nsion cards
x2 Supports PCI expa nsion cards
x1 Each connector supports 2 Flo ppy drives
x2 Each connector supports 2 IDE device
x2 Each connector supports 1 SATA devices
x1 Supports front panel facilities
x1 Supports front panel a udio function
x1 Supports CD audio-in function
