Summary of Contents for Mach P4MSD-800

  • Page 1 P4MSD-800 FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ...............1 Features ....................1 Package List ..................3 Layout....................4 Components..................5 Chapter 2: Hardware Installation ..........6 Central Processing Unit (CPU)............6 FAN Headers..................7 Memory Module Installation ............8 Connectors and Slots ................9 Chapter 3: Headers & Jumpers Setup........10 How to Setup Jumpers ..............10 Detail Settings..................10 Chapter 4: Useful Help ..............14 Award BIOS Beep Code..............14...
  • Page 3: Chapter 1: Introduction

    P4MSD-800 CHAPTER 1: INTRODUCTION EATURES Supports Socket 775. Supports Intel Pentium 4 Prescott processor up to 3.6GHz. Front side bus at the following frequency ranges: 533MT/s (133MHz Core Clock) 800MT/s (200MHze Core Clock) Supports Hyper-Threading Technology. Chipset North Bridge: VIA P4M800.
  • Page 4 P4MSD-800 Slot 3 PCI bus master slots. 1 AGP 4x/8x compatible slot. 1 CNR slot. Serial ATA Integrated in VT8237R. Supports RAID 0 and RAID 1 functions. Supports 2 serial ATA (SATA) ports. Data transfer rates up to 150 MB/s.
  • Page 5: Package List

    P4MSD-800 Rear Side Connectors 4 USB 2.0 ports. 1 VGA port. 1 serial port. 1 parallel port. 1 RJ-45 LAN jack. 1 PS/2 Mouse & Keyboard port. 1 vertical audio port including 1 line-in connector, 1 line out connector, and 1 MIC in connector.
  • Page 6: Layout

    P4MSD-800 AYOUT JKBMS1 JCFAN1 LGA775 JATXPWR2 JCOM1 CPU1 JVGA1 JUSB1 JUSBV1 JUSBLAN1 P4M800 Super JAUDIO BIOS AGP1 BAT1 PCI1 JUSB3 JSATA2 VT8237R PCI2 JAUDIO1 JUSB4 JSPDIFO1 JSATA1 JCDIN1 JUSBV2 PCI3 JCI1 Codec JCMOS1 JPANEL1 CNR1 FDD1 JSFAN1 Note: ■ represents the 1...
  • Page 7: Components

    P4MSD-800 OMPONENTS LGA775 CPU1 P4M800 Super BIOS BAT1 VT8237R Codec JCMOS1: Clear CMOS header. JATXPWR2: ATX power connector. Back panel connectors (rear side). JCI1: Chassis open message header. JUSBV1: USB power header for JUSBV2: USB power header for JKBMS1, JUSB1, and JUSBLAN1.
  • Page 8: Chapter 2: Hardware Installation

    P4MSD-800 CHAPTER 2: HARDWARE INSTALLATION (CPU) ENTRAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged.
  • Page 9: Fan Headers

    P4MSD-800 Step 2-2: Step 3: Hold the CPU down firmly, and then close the lever to complete the installation. Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation.
  • Page 10: Memory Module Installation

    P4MSD-800 EMORY ODULE NSTALLATION Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 11: Connectors And Slots

    P4MSD-800 ONNECTORS AND LOTS The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~5, Bus Master, and Ultra DMA 33/ 66/ 100 functionality.
  • Page 12: Chapter 3: Headers & Jumpers Setup

    P4MSD-800 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened...
  • Page 13 P4MSD-800 JATXPWR1/PATXPWR2: Power Connectors JATXPWR1: This connector allows user to connect with 20-pin power connector on the ATX power supply. JATXPWR2: By connecting this connector, it will provide +12V to CPU power circuit. Assignment Assignment +3.3V +3.3V +3.3V -12V Ground...
  • Page 14 P4MSD-800 JCDIN1: CD-ROM Audio-in Connector This connector allows user to connect the audio source from the veriaty devices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc.. Assignment Left channel input Ground JCDIN1 Ground Right channel input JSPDIFO1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header.
  • Page 15 P4MSD-800 JPANEL1: Front Panel Header This 24-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep button, speaker and IrDA Connection. It allows user to connect the PC case’s front panel switch functions. PWR_LED On/Off HLED JPANEL1 Assignment Function Assignment...
  • Page 16: Chapter 4: Useful Help

    In this Case, please follow the procedure below to restore the BIOS: 1. Make a bootable floppy disk. 2. Download the Flash Utility “AWDFLASH.exe” from the Mach Speed website: www.machspeed.com 3. Confirm motherboard model and download the correct BIOS from the machspeed website.
  • Page 17 P4MSD-800 If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 18: Troubleshooting

    P4MSD-800 ROUBLESHOOTING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, fan securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on keyboard does not turn on.
  • Page 19: Chapter 5: Warpspeeder

    P4MSD-800 WARPSPEEDER™ CHAPTER 5: NTRODUCTION [WarpSpeeder™], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 20: Installation

    P4MSD-800 NSTALLATION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 21: Warpspeeder™] Includes 1 Tray Icon And 5 Panels

    P4MSD-800 ™] PEEDER INCLUDES TRAY ICON AND PANELS Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [WarpSpeeder™] Utility. You can use the mouse by clicking the left button in order to invoke [WarpSpeeder™] directly from the little tray icon or you can...
  • Page 22 P4MSD-800 If you click the tray icon, [WarpSpeeder™] utility will be invoked. Please refer to the following figure; the utility’s first window you will see is Main Panel. Main Panel contains features as follows: a. Display the CPU Speed, CPU external clock, Memory clock, AGP clock, and PCI clock information.
  • Page 23 P4MSD-800 Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not. The default setting is “No”. If you want to get the best performance of overclocking, we recommend you click the option “Yes”.
  • Page 24 P4MSD-800 Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. Overclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 25 P4MSD-800 “Auto-overclock button”: User can click this button and [WarpSpeeder™] will set the best and stable performance and frequency automatically. [WarpSpeeder™] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [WarpSpeeder™] utility will restore to the hardware default...
  • Page 26 P4MSD-800 Click the “about” button in Main Panel, the button will be highlighted and the About Panel will slide out to up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking. You can also get the mainboard’s BIOS model and the Version number of...
  • Page 27 P4MSD-800 Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [WarpSpeeder™] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’...
