I T
NSTALLING HE
P -M A
RE OTOR SSEMBLY
1. Place the motor assembly on a stable flat surface with the wire lead end facing up.
2. With the motor sitting upright, place the glass support frame onto the support flange of the motor housing assembly.
3. Place the motor housing glass shade into the frame.
4. Remove the 4 screws located on the side of the motor housing.
5. Install the glass retainer bracket using the 4 screws removed.
6. Install uplight bulbs (4).
A D :
TTACH OWNROD
1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out)
facing upward.
2. Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin;
remove ball.
3. Feed the wires from top of fan through end of downrod you have chosen and set end of downrod into mounting
collar so the hole in the downrod lines up with the hole in the side of the mounting collar.
4. Insert downrod pin through holes in mounting collar and downrod; slip cotter pin through small hole in end of
downrod pin to hold downrod in place.
5. Tighten jam screws against downrod using a
large flat blade screwdriver to ensure a tight
fit against downrod. Tighten nuts against
mounting collar.
NOTE: Fan has 6 feet of hook-up wire in case you are
using a long extension downrod. Wires can be cut so
only 8 inches or so extend beyond the top of the
downrod to make the electrical connections easier
and safer.
6. Feed wires through collar cover and slide collar
cover down the downrod to top of fan.
7. Feed wires through decorative wire support
bracket so loop opening is at the top. Do not
secure to downrod at this point.
8. Feed wires through canopy and slide canopy
over downrod to lay on top of collar cover.
It will be attached to ceiling later.
9. Feed wires through ball and slide ball over
downrod, past hole in the top end of the
downrod. Insert ball pin (removed in step 2),
slide ball up, and tighten set screw to secure
ball in place.
F
AN
Ball
Canopy
Decorative
Wire Support
Bracket
Collar Cover
Downrod
Pin
Top of
Mounting Collar
Fan Body
5
Hook-up (3)
Wires
Ground
Wire
Downrod
Security Screw
Decorative
Wire Support
Cotter
Pin
Jam Screw
