Regency Ceiling Fans Amani Owner's Manual page 11

I L K (O )
NSTALLATION OF IGHT IT PTION
1. With the fan body installed to the ceiling, remove the switch housing cover from the packing.
2. The cover will have three mounting holes in it unlike the access cover which has a threaded pipe.
3. Install the cover to the light kit to be used by threading on the cover to the threaded pipe on the light kit assembly.
Feed the wires through while installing the cover to the light kit.
Note: Be sure to attach the locking nut to threaded pipe once the cover is attached. This nut will stop the light kit from
coming loose over time.
4. Remove the three screws on the switch housing. (Screws will be used later for mounting light kit to fan)
5. Install the light kit electrical connections to the fan by matching the white wire to the white wire on the fan. Then,
install the power wire from the light kit to the power wire in the fan housing.
6. Install the light kit to the fan using the three screws removed and secure to the fan.
I L K E F (O )
NSTALLATION OF IGHT IT ON XISTING AN PTION
TURN POWER OFF TO FAN
1. To install a light kit, the switch housing cover will need to be removed from the fan and installed onto the light kit.
2. Remove the accent cover plate by turning counter clockwise and removing.
3. With the accent cover plate removed, the three mounting screws that hold the switch housing cover to the switch
housing are exposed. Remove the three screws holding the cover. Once removed, the switch housing cover will come
off and the wire connections are exposed.
4. Attach the switch housing cover to the light kit by threading the cover onto the threaded pipe on the light kit. Feed
the wires through the cover while attaching the cover to the pipe.
Note: Be sure to attach the locking nut to the threaded pipe once the cover is attached. This nut will stop the fixture
from coming loose over time.
5. Attach the wires to matching connection in the switch housing of the fan. Connect the white to the white and then
attach the power wire to the power wire in the fan.
6. With the wires attached, re-install the switch housing cover back on to the fan with the light kit attached using the
three screws removed earlier.
7. Assemble the light kit if needed.
8. Turn the power back on to the fan.
10
